#include "ltwrappr.h"

virtual L_INT LBitmap::BumpMap(pBumpBitmap, pBumpData, uFlags = 0)

virtual L_INT LBitmap::BumpMap(hBumpBitmap, pBumpData, uFlags = 0)

Adds a three-dimensional texture pattern created by applying the bump image to the destination image.



Pointer to the bitmap handle referencing the Bump bitmap.

LBitmap * pBumpBitmap

Pointer to the bitmap object referencing the Bump bitmap.


Pointer to a BUMPDATA structure that contains information about the bump parameter.

L_UINT32 uFlags

Reserved for future use. Must be 0.


Value Meaning
SUCCESS The function was successful.
< 1 An error occurred. Refer to Return Codes.


To update a status bar or detect a user interrupt during execution of this function, refer to LBase::EnableStatusCallback.

This function supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.

This function does not support signed data images. It returns the error code ERROR_SIGNED_DATA_NOT_SUPPORTED if a signed data image is passed to this function.

This function does not support 32-bit grayscale images. It returns the error code ERROR_GRAY32_UNSUPPORTED if a 32-bit grayscale image is passed to this function.

Required DLLs and Libraries


Win32, x64.

See Also




L_INT LBitmap__BumpMapExample(LAnimationWindow *BitmapWindow)
   L_INT nRet;
   BUMPDATA BumpData;
   LBitmap Bitmap, PaintBitmap;
   nRet =Bitmap.Load(MAKE_IMAGE_PATH(TEXT("ImageProcessingDemo\\Image1.jpg")), 0,ORDER_BGR);
   if(nRet !=SUCCESS)
      return nRet;
   BumpData.uStructSize = sizeof(BUMPDATA);
   BumpData.bTile    = TRUE;
   BumpData.nAzimuth = 5;
   BumpData.nBright    = 50;
   BumpData.nIntensity = 0;
   BumpData.nXDst = 0;
   BumpData.nYDst = 0;
   BumpData.nXOffset = 0;
   BumpData.nYOffset = 0;
   BumpData.uDepth = 3;
   BumpData.uElevation = 0;
   BumpData.pLut = NULL;
   nRet =BitmapWindow->BumpMap(&Bitmap,&BumpData);
   if(nRet !=SUCCESS)
      return nRet;
   return SUCCESS;
