The following table shows all the third-party native dependencies used by LEADTOOLS. To determine which libraries require these dependencies, refer to the list at the end of this document. A table showing which LEADTOOLS library supports which features can be found here.
| Library | Description | Ubuntu Package Name | Fedora Package Name |
|---|---|---|---|
| uuid | Universally Unique Identifier library | uuid-dev | uuid-devel |
| uuid-runtime | uuidd | ||
| gcc | GNU compiler collection | gcc | gcc |
| g++ | GNU C++ compiler | g++ | gcc-c++ |
| glibc-devel | Standard C library | libc-dev-bin | glibc-devel |
| kernel | kernel development libraries and headers | linux-libc-dev | kernel-devel kernel-headers |
| X11 | Core X11 protocol client library | libx11-6 | libX11 |
| libxt6 | libXt | ||
| X11-devel | Development files for libX11 | libx11-dev | libX11-devel |
| libxt-dev | libXt-devel | ||
| sqllite | C library that implements a SQL database engine | sqlite3 | sqlite |
| sqlite-devel | Development header files for sqlite | libsqlite-dev | sqlite-devel |
| freetype >= 2.3.8 | Font rendering engine | libfreetype6 | freetype |
| fontconfig >= 2.8.0 | Locates fonts within the system | fontconfig | fontconfig |
| Microsoft Core Fonts. See Notes below. | Microsoft True Type Core Fonts | ttf-mscorefonts-installer | See Installing Microsoft True Type Core Fonts below |
The following are the minimum versions required by the LEADTOOLS 23 toolkit:
| OS | Version |
|---|---|
| CentOS/Redhat | 7.9 |
| Fedora | 23 |
| Ubuntu | 16.04 |
| Debian | 9 |
Note
The LEADTOOLS OCR, Documents format readers, and Documents format writers modules will try to create fonts during their operation. If a needed font, such as "Arial" or "Times New Roman" is not found on the system, the module will substitute a different font. If an exact match for the module output between Windows and Linux is required, then the Microsoft Core Fonts component must be installed.
Issue the following command to install the dependencies in Ubuntu:
sudo apt update &&sudo apt-get install uuid-dev uuid-runtime gcc g++ libc-dev-bin linux-libc-dev libx11-6 libx11-dev libxt6 libxt-dev sqlite3 libsqlite3-dev libfreetype6 fontconfig ttf-mscorefonts-installer
Issue the following command to install the dependencies in Fedora:
sudo dnf install uuid-devel uuidd gcc gcc-c++ glibc-devel kernel-devel kernel-headers libX11 libX11-devel libXt libXt-devel sqlite sqlite-devel freetype fontconfig
Issue the following commands to install the dependencies in CentOS/Redhat
sudo yum update -ysudo yum install libuuid libuuid-devel uuidd gcc gcc-c++ glibc-devel kernel-devel kernel-headers libX11 libXt libX11-devel libXt-devel sqlite sqlite-devel freetype fontconfig -y
Installing Microsoft True Type Core Fonts
Issue the following commands to install Microsoft TrueType Core Fonts:
sudo dnf install rpm-build cabextract ttmkfdir wgetcd ~ && mkdir tmp && cd tmpwget http://corefonts.sourceforge.net/msttcorefonts-2.5-1.specsudo rpmbuild -bb msttcorefonts-2.5-1.specsudo dnf install /root/rpmbuild/RPMS/noarch/msttcorefonts-2.5-1.noarch.rpm
Install the Java Development Kit (JDK) and Java Runtimes (JRE). For a table of LEADTOOLS JAR files and their native dependencies refer to Files to be Included with your Java Application.
| Library | Description | Ubuntu Package Name | Fedora Package Name | Centos/Redhat Package Name |
|---|---|---|---|---|
| Java JRE | Java Runtime Environment | openjdk-8-jre | java-1.8.0-openjdk | java-1.8.0-openjdk |
| Java JDK | Java Development Toolkit | openjdk-8-jdk | java-1.8.0-openjdk-devel | java-1.8.0-openjdk-devel |
Note
The LEADTOOLS Java Document Service requires Java 11. The below packages meet this requirement.
Library Description Ubuntu Package Name Fedora Package Name Centos/Redhat Package Name Java JRE Java Runtime Environment openjdk-11-jre java-11-openjdk java-11-openjdk Java JDK Java Development Toolkit openjdk-11-jdk java-11-openjdk-devel java-11-openjdk-devel
Issue the following command to install the Java Development Kit and Java Runtimes in Ubuntu:
sudo apt-get install openjdk-8-jre openjdk-8-jdk
Issue the following command to install the Java Development Kit and Java Runtimes in Fedora:
sudo dnf install java-1.8.0-openjdk java-1.8.0-openjdk-devel
Issue the following command to install the Java Development Kit and Java Runtimes in Centos/Redhat:
sudo yum install java-1.8.0-openjdk java-1.8.0-openjdk-devel
For step-by-step tutorials containing instructions on building and running LEADTOOLS demos, refer to Build and Run LEADTOOLS Demos on Linux for Java and Build and Run LEADTOOLS Demos on Linux for C/C++.
These are the dependencies that are common within all of the Library Dependencies.
There are certain Shared Library Dependencies that have additional dependencies to the ones listed above. You can see a table of those below.
| Shared Library | Dependencies |
|---|---|
| liblfbmp.so, liblfcmp.so, liblfcmw.so, liblfeps.so, liblffax.so, liblfgif.so, liblfimg.so, liblfj2k.so, liblfjb2.so, liblfjbg.so, liblfjxr.so, liblflmb.so, liblfpcx.so, liblfpng.so, liblfpsd.so, liblfraw.so, | No additional dependencies, see above list for all required dependencies |
| libleadtools.barcode.datamatrixread.so, libleadtools.barcode.datamatrixwrite.so, libleadtools.barcode.oned.so, libleadtools.barcode.pdfread.so, libleadtools.barcode.pdfwrite.so, libleadtools.barcode.qrread.so, libleadtools.barcode.qrwrite.so, libltdic.so, libltdictables.so, libltfil.so, libltimgutl.so | libpthread, libdl |
| libleadtools.barcode.lead2dread.so, libleadtools.barcode.lead2dwrite.so | libpthread, libdl, libltimgcor |
| liblfcal.so, liblfica.so, liblftif.so | liblffax |
| liblfcgm.so, liblfcmx.so, liblfdxf.so, liblfe00.so, liblfgbr.so, liblfmif.so, liblfnap.so, liblfpct.so, liblfshp.so, liblfvpg.so | libltdrw, libltvkrn |
| liblfdox.so, liblftxt.so | libltdrw |
| liblfdwg.so | libltdrw, libltvkrn, libltimgclr |
| liblfjls.so | libltimgclr |
| liblfpcl.so | libltdrw, libltvkrn, libltimgcor |
| liblfppx.so, liblfxlx.so | libltdrw, libltimgclr |
| libltbar.so | libpthread, libdl, librt, libltimgcor |
| libltclr.so | libpthread, libdl, libltfil |
| libltdocwrt.so | libpthread, libdl, libltfil, libltimgcor, libltimgclr, libltsvg, libltdrw |
| libltdrw.so | libpthread, libdl, libfontconfig, libfreetype, libGL |
| libltimgclr.so, libltimgcor.so, libltimgefx.so | libpthread, libdl, libltimgutl |
| libltjp2.so | libpthread, libdl, libltfil, libltimgefx |
| libltkrn.so | libpthread, libdl, libuuid, librt |
| libltocr.so | libpthread, libdl, libltfil, libltimgcor, libltimgefx, libltimgclr, libltdocwrt, libltdrw |
| libltpdf.so | libpthread, libdl, libltfil, liblffax, libltdrw |
| libltsane.so | libpthread, libdl, libsane |
| libltsvg.so | libpthread, libdl, libltfil, libltvkrn, libltdrw |
| libltvkrn.so | libltfil, libltimgcor, libltimgefx, libltdrw |
