HistogramEqualizeCommand Class

Summary
Linearizes the number of pixels, in an image, based on the specified color space. This can be used to bring out the detail in dark areas of an image. This function is useful for pre-processing images for the purpose of improving barcode recognition results.
Syntax
C#
Objective-C
C++/CLI
Java
Python
public class HistogramEqualizeCommand : RasterCommand
@interface LTHistogramEqualizeCommand : LTRasterCommand
public class HistogramEqualizeCommand
    extends RasterCommand
public ref class HistogramEqualizeCommand : public RasterCommand
class HistogramEqualizeCommand(RasterCommand):
Remarks
  • Previously this class only equalized the number of pixels per gray level, using a gray level representation of the image. This functionality is now obtained by passing HistogramEqualizeType.Gray for the Type property.
  • For the best results, set Type to HistogramEqualizeType.Yuv
  • This class can process the whole image or a region of the image.
  • This class supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
  • This command does not support 32-bit grayscale images.
  • This command supports signed/unsigned data images.

For more information, refer to Changing Brightness and Contrast.

Histogram Equalize Function - Before

Histogram Equalize Function - Before

Histogram Equalize Function - After

Histogram Equalize Function - After

View additional platform support for this Histogram Equalize function.

Example

Run the HistogramEqualizeCommand on an image and apply histogram equalization with YUV color space.

C#
Java
using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Color;


public void HistogramEqualizeCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "IMAGE1.CMP"));

   // Prepare the command
   HistogramEqualizeCommand command = new HistogramEqualizeCommand();
   //Histogram equalize the image.
   command.Type = HistogramEqualizeType.Yuv;
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}

import java.io.File;
import java.io.IOException;

import org.junit.*;
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
import static org.junit.Assert.assertTrue;

import leadtools.*;
import leadtools.codecs.*;
import leadtools.imageprocessing.color.HistogramEqualizeCommand;
import leadtools.imageprocessing.color.HistogramEqualizeType;


public void histogramEqualizeCommandExample() {
   final String LEAD_VARS_IMAGES_DIR = "C:\\LEADTOOLS23\\Resources\\Images";

   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.setThrowExceptionsOnInvalidImages(true);

   RasterImage image = codecs.load(combine(LEAD_VARS_IMAGES_DIR, "IMAGE1.CMP"));

   // Prepare the command
   HistogramEqualizeCommand command = new HistogramEqualizeCommand();

   // Histogram equalize the image.
   command.setType(HistogramEqualizeType.YUV);
   command.run(image);
   codecs.save(image, combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"), RasterImageFormat.JPEG, 24);

   assertTrue(new File(combine(LEAD_VARS_IMAGES_DIR, "Result.jpg")).exists());
   System.out.println("Command run and image saved to " + combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"));
}
