GammaCorrectCommand Class

Summary

Adjusts the intensity of colors in an image by changing the gamma constant that is used to map the intensity values.

Syntax

Objective-C

C++/CLI

Java

Python

public class GammaCorrectCommand : RasterCommand

@interface LTGammaCorrectCommand : LTRasterCommand

public class GammaCorrectCommand
    extends RasterCommand

public ref class GammaCorrectCommand : public RasterCommand

class GammaCorrectCommand(RasterCommand):

Remarks

Intensity values ideally follow a logarithmic progression, because the eye perceives changes in intensity as being equal when the ratio of change is equal. For example, we would see a change from 0.1 to 0.2 as being equal to a change from 0.2 to 0.4.
Gamma is a standard constant that is used to calculate the progression. For most CRTs the gamma constant is in the range of 2.2 to 2.5.
This class supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
This command does not support 32-bit grayscale images.

For more information, refer to Changing Brightness and Contrast.

If the image has a LUT and you want to work on the image data, set RasterImage.UseLookupTable to false. Then, after calling the method, reset the UselookupTable property to true, as follows:

rasterImage.UseLookupTable = false;
Method(rasterImage);
rasterImage.UseLookupTable = true;

Gamma Correct Function - Before

Gamma Correct Function - After

View additional platform support for this Gamma Correct function.

Example

Run the GammaCorrectCommand on an image and apply gamma correction.

Java

using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Color;


public void GammaCorrectCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "sample5.cmp"));

   // Prepare the command
   GammaCorrectCommand command = new GammaCorrectCommand();
   //Set a gamma value of 2.5.
   command.Gamma = 250;
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}


import java.io.File;
import java.io.IOException;

import org.junit.*;
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
import static org.junit.Assert.*;

import leadtools.*;
import leadtools.codecs.*;
import leadtools.imageprocessing.color.GammaCorrectCommand;


public void gammaCorrectCommandExample() {

   final String LEAD_VARS_IMAGES_DIR = "C:\\LEADTOOLS23\\Resources\\Images";

   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.setThrowExceptionsOnInvalidImages(true);

   RasterImage image = codecs.load(combine(LEAD_VARS_IMAGES_DIR, "sample5.cmp"));
   String outputFileName = combine(LEAD_VARS_IMAGES_DIR, "Result.jpg");

   // Prepare the command
   GammaCorrectCommand command = new GammaCorrectCommand();
   // Set a gamma value of 2.5.
   command.setGamma(250);
   command.run(image);
   System.out.println("Executed changes on loaded image...");

   codecs.save(image, outputFileName, RasterImageFormat.JPEG, 24);
   System.out.println("Command run and image saved to " + outputFileName);
   assertTrue(new File(outputFileName).exists());

}
