SelectiveColorCommand Class

Summary

Changes the color of an image by altering the definitions of one or more colors used by the image. This class is available in the Imaging and above toolkits.

Syntax

Objective-C

C++/CLI

Java

Python

public class SelectiveColorCommand : RasterCommand

@interface LTSelectiveColorCommand : LTRasterCommand

public class SelectiveColorCommand
    extends RasterCommand

public ref class SelectiveColorCommand : public RasterCommand

class SelectiveColorCommand(RasterCommand):

Remarks

Selected colors are the additive colors (Red, Green and Blue), the subtractive colors (Cyan, Magenta and Yellow), the highlights (White), the midtones (Neutral) and the shadows (Black). Each of those “Selected Colors" has information about the percentages of cyan, magenta, yellow and black that constructs that selective color. Each unique pixel's color can be defined as using some certain percentage of CMYK values. By changing the percentage of CMYK values for a "selected color", all colors related to that "selected color" would change also. For example, you can decrease the Magenta percentage from the "Blue selected color" to change a blue color to a color that is more similar to Cyan. Also you can increase the Yellow percentage from the "Magenta selected color" to change magenta color to a color that is more similar to Red.
You control the percentage of CMYK for each of the selected colors using the members of a SelectiveColorCommandData class, which are, Cyan, Magenta, Yellow and Black. Each member takes a value from -100 to 100. Negative values for any of these members decrease the percentage of that color, whereas positive values increase the percentage of that color. If Cyan = -100 it means no cyan will be used, whereas if Cyan = 100 it means the full percentage of cyan will be used. If a value is out of range, a negative value goes to -100 and a positive value goes to 100.
Pixel colors are changed based on HSV color space. For example, if you alter the values for ColorsData[SelectiveCommandColorTypes.Red], then if a pixel value is within the RED range of the Hue scale, it is considered red and is changed using the settings in ColorsData[ColorSeparateCommandType.Red].
This command supports 48 and 64-bit color images. Support for 48 and 64-bit color images is available only in the Document/Medical toolkits.
This command does not support signed data images.
This command does not support 32-bit grayscale images.

For more information, refer to Correcting Colors.

Selective Color Function - Before

Selective Color Function - After

View additional platform support for this Selective Color function.

Example

Run the SelectiveColorCommand on an image and apply selective color to the image.

Java

using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Color;


public void SelectiveColorCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "cannon.jpg"));

   // Prepare the command
   SelectiveColorCommand command = new SelectiveColorCommand();
   //Manipulate values.
   command.ColorsData[(int)SelectiveCommandColorTypes.Red].Cyan = -100; // Change the Red selected color
   command.ColorsData[(int)SelectiveCommandColorTypes.Yellow].Cyan = 34;  // Change the Yellow selected color
   command.ColorsData[(int)SelectiveCommandColorTypes.Yellow].Magenta = 100;
   command.ColorsData[(int)SelectiveCommandColorTypes.Yellow].Yellow = 40;
   command.ColorsData[(int)SelectiveCommandColorTypes.Green].Black = 100; // Change the Green selected color
   command.ColorsData[(int)SelectiveCommandColorTypes.Neutral].Cyan = -65;  // Change the Neutral selected color
   command.ColorsData[(int)SelectiveCommandColorTypes.Neutral].Magenta = -39;
   command.ColorsData[(int)SelectiveCommandColorTypes.Neutral].Yellow = 63;
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}


import java.io.File;
import java.io.IOException;
import org.junit.*;
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
import static org.junit.Assert.*;

import leadtools.*;
import leadtools.codecs.*;
import leadtools.imageprocessing.color.*;


public void selectiveColorCommandExample() {
   final String LEAD_VARS_IMAGES_DIR = "C:\\LEADTOOLS23\\Resources\\Images";

   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.setThrowExceptionsOnInvalidImages(true);

   RasterImage image = codecs.load(combine(LEAD_VARS_IMAGES_DIR, "cannon.jpg"));

   // Prepare the command
   SelectiveColorCommand command = new SelectiveColorCommand();

   // Manipulate values.
   command.getColorsData()[SelectiveCommandColorTypes.RED.getValue()].setCyan(-100); // Change the Red selected color
   command.getColorsData()[SelectiveCommandColorTypes.YELLOW.getValue()].setCyan(34); // Change the Yellow
   // selectedcolor

   command.getColorsData()[SelectiveCommandColorTypes.YELLOW.getValue()].setMagenta(-100);
   command.getColorsData()[SelectiveCommandColorTypes.YELLOW.getValue()].setYellow(40);
   command.getColorsData()[(int) SelectiveCommandColorTypes.GREEN.getValue()].setBlack(100); // Change the Green
   // selected color

   command.getColorsData()[(int) SelectiveCommandColorTypes.NEUTRAL.getValue()].setCyan(-65); // Change the Neutral
   // selected color

   command.getColorsData()[(int) SelectiveCommandColorTypes.NEUTRAL.getValue()].setMagenta(-39);
   command.getColorsData()[(int) SelectiveCommandColorTypes.NEUTRAL.getValue()].setYellow(63);

   command.run(image);
   codecs.save(image, combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"), RasterImageFormat.JPEG, 24);

   assertTrue(new File(combine(LEAD_VARS_IMAGES_DIR, "Result.jpg")).exists());
   System.out.println("Command run, file saved to " + combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"));
}
