SwapColorsCommand Class

Summary

Swaps the specified color channels.

Syntax

Objective-C

C++/CLI

Java

Python

public class SwapColorsCommand : RasterCommand

@interface LTSwapColorsCommand : LTRasterCommand

public class SwapColorsCommand
    extends RasterCommand

public ref class SwapColorsCommand : public RasterCommand

class SwapColorsCommand(RasterCommand):

Remarks

This command changes the image data.
This command supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
This command supports signed data images.
This command does not support 32-bit grayscale images.

For more information, refer to Correcting Colors.

Swap Colors Function - Before

Swap Colors Function - After

View additional platform support for this Swap Colors function.

Example

Run the SwapColorsCommand on an image.

Java

using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Color;


public void SwapColorsCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "cannon.jpg"));

   // Prepare the command
   SwapColorsCommand command = new SwapColorsCommand();
   command.Type = SwapColorsCommandType.RedGreen;
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}


import java.io.File;
import java.io.IOException;

import org.junit.*;
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
import static org.junit.Assert.*;

import leadtools.*;
import leadtools.codecs.*;
import leadtools.imageprocessing.color.*;


public void swapColorsCommandExample() {

   final String LEAD_VARS_IMAGES_DIR = "C:\\LEADTOOLS23\\Resources\\Images";

   // Load an Image
   RasterCodecs codecs = new RasterCodecs();
   codecs.setThrowExceptionsOnInvalidImages(true);

   RasterImage image = codecs.load(combine(LEAD_VARS_IMAGES_DIR, "cannon.jpg"));

   // Prepare the command
   SwapColorsCommand command = new SwapColorsCommand();
   command.setType(SwapColorsCommandType.RED_GREEN);
   command.run(image);
   codecs.save(image, combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"), RasterImageFormat.JPEG, 24);

   System.out.println("Command run and image saved to " + combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"));
   assertTrue(new File(LEAD_VARS_IMAGES_DIR).exists());

}
