ChangeContrastCommand Class

Summary
Increases or decreases the contrast of the image.
Syntax
C#
Objective-C
C++/CLI
Java
Python
public class ChangeContrastCommand : RasterCommand
@interface LTChangeContrastCommand : LTRasterCommand
public class ChangeContrastCommand
    extends RasterCommand
public ref class ChangeContrastCommand : public RasterCommand
class ChangeContrastCommand(RasterCommand):
Remarks
  • This command supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
  • This command does not support 32-bit grayscale images.
  • This command supports signed/unsigned data images.

If the image has a LUT and you want to work on the image data, set RasterImage.UseLookupTable to false. Then, after calling the method, reset the UselookupTable property to true, as follows:

rasterImage.UseLookupTable = false;
Method(rasterImage);
rasterImage.UseLookupTable = true;

For more information, refer to Changing Brightness and Contrast.

Change Contrast Function - Before

Change Contrast Function - Before

Change Contrast Function - After

Change Contrast Function - After

View additional platform support for this Change Contrast function.

Example

Runs the ChangeContrastCommand on an image and increases its contrast.

C#
Java
using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Color;


public void ChangeContrastCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "ImageProcessingDemo\\Image1.jpg"));

   // Prepare the command
   ChangeContrastCommand command = new ChangeContrastCommand();
   //Increase the contrast  by 25 percent  of the possible range.
   command.Contrast = 250;
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}

import java.io.File;
import java.io.IOException;

import org.junit.*;
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
import static org.junit.Assert.*;

import leadtools.*;
import leadtools.codecs.*;
import leadtools.imageprocessing.color.*;


public void changeContrastCommandExample() {

    final String LEAD_VARS_IMAGES_DIR = "C:\\LEADTOOLS23\\Resources\\Images";
    // Load an image
    RasterCodecs codecs = new RasterCodecs();
    codecs.setThrowExceptionsOnInvalidImages(true);

    RasterImage image = codecs.load(combine(LEAD_VARS_IMAGES_DIR, "Image1.jpg"));

    // Prepare the command
    ChangeContrastCommand command = new ChangeContrastCommand();
    // Increase the contrast by 25 percent of the possible range
    command.setContrast(250);
    command.run(image);
    codecs.save(image, combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"), RasterImageFormat.JPEG, 24);

    System.out.println("Command run and image saved to " + combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"));
    assertTrue(new File(LEAD_VARS_IMAGES_DIR, "Result.jpg").exists());

}
