ChangeHueCommand Class

Summary

Changes the hue of colors in an image by rotating the color wheel.

Syntax

Objective-C

C++/CLI

Java

Python

public class ChangeHueCommand : RasterCommand

@interface LTChangeHueCommand : LTRasterCommand

public class ChangeHueCommand
    extends RasterCommand

public ref class ChangeHueCommand : public RasterCommand

class ChangeHueCommand(RasterCommand):

Remarks

This command can rotate the color wheel in either direction. A 180-degree rotation in either direction changes each color to its complement. Positive rotation takes red toward green, green toward blue, and blue toward red. Negative rotation has the opposite effect.
This command supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
This command does not support signed data images.
This command does not support 32-bit grayscale images.

For more information, refer to Changing Brightness and Contrast. For more information, refer to Correcting Colors.

Change Hue Function - Before

Change Hue Function - After

View additional platform support for this Change Hue function.

Example

Run the ChangeHueCommand on an image and change its hue.

Java

using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Color;


public void ChangeHueCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "ImageProcessingDemo\\Image1.jpg"));

   // Prepare the command
   ChangeHueCommand command = new ChangeHueCommand();
   //Change each color to its complement.
   command.Angle = 180;
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}


import java.io.File;
import java.io.IOException;

import org.junit.*;
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
import static org.junit.Assert.*;

import leadtools.*;
import leadtools.codecs.*;
import leadtools.imageprocessing.color.ChangeHueCommand;


public void changeHueCommandExample() {

   final String LEAD_VARS_IMAGES_DIR = "C:\\LEADTOOLS23\\Resources\\Images";

   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.setThrowExceptionsOnInvalidImages(true);

   RasterImage image = codecs.load(combine(LEAD_VARS_IMAGES_DIR, "Image1.jpg"));

   // Prepare the command
   ChangeHueCommand command = new ChangeHueCommand();

   // Change each color to its complement
   command.setAngle(180);
   command.run(image);
   codecs.save(image, combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"), RasterImageFormat.JPEG, 24);

   assertTrue(new File(combine(LEAD_VARS_IMAGES_DIR, "Result.jpg")).exists());
   System.out.println("Command run and image saved to " + combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"));

}
