ColorLevelCommand Class

Summary

Applies color leveling to an image. It changes the image shadows, midtones and highlights. This function is useful for pre-processing images for the purpose of improving barcode recognition results.

Syntax

Objective-C

C++/CLI

Java

Python

public class ColorLevelCommand : RasterCommand

@interface LTColorLevelCommand : LTRasterCommand

public class ColorLevelCommand
    extends RasterCommand

public ref class ColorLevelCommand : public RasterCommand

class ColorLevelCommand(RasterCommand):

Remarks

The members of the ColorLevelCommandData class tell the ColorLevelCommand what constitutes shadows, midtones, and highlights and how to remap the shadows, midtones and highlights.
Control the amount of image balance and leveling by controlling the values of the MinimumInput, MaximumInput, MinimumOutput, MaximumOutput, and Gamma members of the ColorLevelCommandData class.
- The MinimumInput property of the ColorLevelCommandData class defines what the method interprets as shadows for that color channel. Any value less than or equal to MinimumInput is considered a shadow.
- The MaximumInput property of the ColorLevelCommandData class defines what the method interprets as highlights for that color channel. Any value greater than or equal to MaximumInput is considered a highlight.
- The value of the MaximumInput property must be greater than the value of the MinimumInput property by at least 2.
- Midtones are those values between MinimumInput and MaximumInput.
- The MinimumOutput property is the value to which the shadows will be mapped.
- The MaximumOutput property is the value to which the highlights will be mapped.
- The Gamma property is used to modify the midtone values
If only ColorLevelCommandFlags.Master is set in the Flags property, then the rest of the channels will still be affected.
If the image is a grayscale image, then you must set ColorLevelCommandFlags.Master in the Flags property, otherwise the class will not have any effect.
If MinimumOutput > MaximumOutput then the image's shadows and highlights will be inverted.
This command does not support 12 and 16-bit grayscale.
This command supports 48 and 64-bit color images. Support for 48 and 64-bit color images is available only in the Document/Medical toolkits.
This command does not support signed data images.

For more information, refer to Changing Brightness and Contrast. For more information, refer to Correcting Colors.

Color Level Function - Before

Color Level Function - After

View additional platform support for this Color Level function.

Example

Run the ColorLevelCommand on an image.

Java

using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Color;


public void ColorLevelCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "IMAGE1.CMP"));

   // Prepare the command
   ColorLevelCommandData blue = new ColorLevelCommandData(0, 255, 255, 0, 100);
   ColorLevelCommandData master = new ColorLevelCommandData(20, 200, 0, 255, 100);
   ColorLevelCommandData red = new ColorLevelCommandData(0, 255, 0, 255, 100);
   ColorLevelCommandData green = new ColorLevelCommandData(0, 255, 0, 255, 100);

   // Level the Blue and Master channels
   ColorLevelCommand command = new ColorLevelCommand();
   command.Blue = blue;
   command.Red = red;
   command.Green = green;
   command.Master = master;
   command.Flags = ColorLevelCommandFlags.Blue | ColorLevelCommandFlags.Master;
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}


import java.io.File;
import java.io.IOException;

import org.junit.*;
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
import static org.junit.Assert.assertTrue;

import leadtools.*;
import leadtools.codecs.*;
import leadtools.imageprocessing.color.*;


public void colorLevelCommandExample() {

    final String LEAD_VARS_IMAGES_DIR = "C:\\LEADTOOLS23\\Resources\\Images";

    // Load an image
    RasterCodecs codecs = new RasterCodecs();
    codecs.setThrowExceptionsOnInvalidImages(true);

    RasterImage image = codecs.load(combine(LEAD_VARS_IMAGES_DIR, "IMAGE1.CMP"));

    // Prepare the command
    ColorLevelCommandData blue = new ColorLevelCommandData(0, 255, 255, 0, 100);
    ColorLevelCommandData master = new ColorLevelCommandData(20, 200, 0, 255, 100);
    ColorLevelCommandData red = new ColorLevelCommandData(0, 255, 0, 255, 100);
    ColorLevelCommandData green = new ColorLevelCommandData(0, 255, 0, 255, 100);

    // Level the Blue and Master channels
    ColorLevelCommand command = new ColorLevelCommand();
    command.setBlue(blue);
    command.setRed(red);
    command.setGreen(green);
    command.setMaster(master);
    command.setFlags(ColorLevelCommandFlags.BLUE.getValue() | ColorLevelCommandFlags.MASTER.getValue());
    command.run(image);

    String outputFilePath = combine(LEAD_VARS_IMAGES_DIR, "Result.jpg");
    codecs.save(image, outputFilePath, RasterImageFormat.JPEG, 24);

    System.out.println("Command run and image saved to " + outputFilePath);
    assertTrue(new File(outputFilePath).exists());
}
