SigmaCommand Class

Summary

Performs an edge preserving average filter on bitmap.

Syntax

Objective-C

C++/CLI

Python

public class SigmaCommand : RasterCommand

@interface LTSigmaCommand : LTRasterCommand

public ref class SigmaCommand : public RasterCommand

class SigmaCommand(RasterCommand):

Remarks

The amount of blur is controlled by specifying the size of the neighborhood.
This command supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
This command does not support 32-bit grayscale images.

Sigma Function - Before

Sigma Function - After

View additional platform support for this Sigma function.

Example

Runs the SigmaCommand on the Image.

using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Core;

public void SigmaCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "sample5.cmp"));

   // Prepare the command
   SigmaCommand command = new SigmaCommand();
   //Apply
   command.Dimension = 10;
   command.Sigma = 2;
   command.Threshold = 0.2f;
   command.Outline = false;
   command.Run(image);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}
