AverageCommand Class

Summary

Changes the color of each pixel in an image to the average color of pixels in its neighborhood. This results in a blur effect.

Syntax

Objective-C

C++/CLI

Java

Python

public class AverageCommand : RasterCommand

@interface LTAverageCommand : LTRasterCommand

public class AverageCommand
    extends RasterCommand

public ref class AverageCommand : public RasterCommand

class AverageCommand(RasterCommand):

Remarks

You control the amount of blur by specifying the size of the neighborhood that is used for averaging.
This command supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
This command does not support 32-bit grayscale images.
This command supports signed/unsigned data images.

For more information, refer to Removing Noise.

Average Filter Function - Before

Average Filter Function - After

View additional platform support for this Average Filter function.

Example

Run the AverageCommand on an image with a neighborhood Dimensions = 3x3 pixels.

Java

using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Effects;


public void AverageCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "sample2.cmp"));

   // Prepare the command
   AverageCommand command = new AverageCommand();
   // Average with a neighborhood of 3x3 pixels
   command.Dimension = 3;
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}


import java.io.File;
import java.io.IOException;

import org.junit.*;
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
import static org.junit.Assert.*;

import leadtools.*;
import leadtools.codecs.*;
import leadtools.imageprocessing.effects.AverageCommand;


public void averageCommandExample() {
    final String LEAD_VARS_IMAGES_DIR = "C:\\LEADTOOLS23\\Resources\\Images";

    // Load an image
    RasterCodecs codecs = new RasterCodecs();
    codecs.setThrowExceptionsOnInvalidImages(true);

    RasterImage image = codecs.load(combine(LEAD_VARS_IMAGES_DIR, "sample2.cmp"));

    // Prepare the command
    AverageCommand command = new AverageCommand();

    // Average with a neighorhood of 3x3 pixels
    command.setDimension(3);
    int change = command.run(image);
    assertTrue(change != RasterImageChangedFlags.NONE);

    codecs.save(image, combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"), RasterImageFormat.JPEG, 24);
    System.out.println("Command run and output image saved to " + combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"));
}
