LAnnEncrypt::GetSecondaryMetafile

#include "ltwrappr.h"

virtual L_INT LAnnEncrypt::GetSecondaryMetafile(phMetafile)

HMETAFILE * phMetafile;

pointer to a variable to be updated with the handle to a metafile

Retrieves the metafile handle associated with an encryptor object when it is in the decryptor state.

Parameter

Description

phMetafile

Pointer to a variable to be updated with the handle to a metafile.

Returns

SUCCESS

The function was successful.

< 1

An error occurred. Refer to Return Codes.

Comments

The encrypt object has two states:

Each state is displayed with its own metafile.

Use this function to retrieve the current metafile for an encrypt object in a decryptor state. The default image is shown in the figure below:


If this function is successful, the address pointed to by phMetafile will be updated with the metafile handle.

Use the LAnnEncrypt::GetMetafile function to retrieve the current metafile for an encrypt object in an encryptor state.

Required DLLs and Libraries

LTANN

For a listing of the exact DLLs and Libraries needed, based on the toolkit version, refer to Files To Be Included With Your Application.

Platforms

Win32, x64.

See Also

Functions:

Class Members, LBitmap::Scramble, LAnnEncrypt::GetEncryptOptions, LAnnEncrypt::SetEncryptOptions, LAnnContainer::EncryptApply, LAnnEncrypt::GetSecondaryMetafile, LAnnStamp::GetSecondaryMetafile, LAnnPoint::GetPredefinedBitmap, LAnnPoint::SetPredefinedBitmap, LAnnPoint::GetPointOptions

Topics:

Annotation Functions: Object Properties



Implementing Annotations



Automated User Interface for Annotations



Annotation Functions: Creating and Deleting Annotations



Annotation Functions: Implementing Custom Annotations



Using Annotation Bitmap Objects

Example

// This example swaps the metafiles for the 'encrypt' and 'decrypt' state of an encryptor

L_INT LAnnEncrypt_GetSecondaryMetafileExample(LAnnEncrypt *pLEncrypt)
{
   L_INT nRet;
   HMETAFILE hMetafile1=0;

   HMETAFILE hMetafile2=0;

   L_BOOL bEncryptorOriginal;

   ANNENCRYPTOPTIONS EncryptOptions;

   L_UINT uObjectType;

   uObjectType = pLEncrypt->GetType();

   if (uObjectType != ANNOBJECT_ENCRYPT)
   {
      MessageBox(NULL, TEXT("This object is not an encryptor."), TEXT("Error"), MB_OK);
      return FAILURE;
   }

   nRet = pLEncrypt->GetMetafile(&hMetafile1);
   if(nRet != SUCCESS)
      return nRet;

   nRet = pLEncrypt->GetSecondaryMetafile(&hMetafile2);
   if(nRet != SUCCESS)
      return nRet;



   memset(&EncryptOptions, 0, sizeof(ANNENCRYPTOPTIONS));

   EncryptOptions.uStructSize = sizeof(ANNENCRYPTOPTIONS);

   EncryptOptions.uFlags = ANNENCRYPT_ALL;

   nRet = pLEncrypt->GetEncryptOptions(&EncryptOptions);
   if(nRet != SUCCESS)
      return nRet;



   bEncryptorOriginal = EncryptOptions.bEncryptor;



   // Set state to encryptor, and set encryptor metafile

   EncryptOptions.uFlags = ANNENCRYPT_TYPE;

   EncryptOptions.bEncryptor = TRUE;

   nRet = pLEncrypt->SetEncryptOptions(&EncryptOptions, 0);
   if(nRet != SUCCESS)
      return nRet;

   nRet = pLEncrypt->SetMetafile(hMetafile2, ANNMETAFILE_USER, 0);
   if(nRet != SUCCESS)
      return nRet;



   // Set state to decryptor, and set decryptor metafile

   EncryptOptions.bEncryptor = FALSE;

   nRet = pLEncrypt->SetEncryptOptions(&EncryptOptions, 0);
   if(nRet != SUCCESS)
      return nRet;

   nRet = pLEncrypt->SetMetafile(hMetafile1, ANNMETAFILE_USER, 0);
   if(nRet != SUCCESS)
      return nRet;



   // Set encryptor to original state

   EncryptOptions.bEncryptor = bEncryptorOriginal;

   nRet = pLEncrypt->SetEncryptOptions(&EncryptOptions, 0);
   if(nRet != SUCCESS)
      return nRet;

   return SUCCESS;
}
