LensFlareCommand Class

Summary
Simulates the secondary reflections caused when bright lights are facing the camera lens. The lens flare is refracted into a series of lightened circles that surround the flare. This method is available in the Imaging and above toolkits.
Syntax
C#
C++/CLI
Python
public class LensFlareCommand : RasterCommand
public ref class LensFlareCommand : public RasterCommand
class LensFlareCommand(RasterCommand):
Remarks
  • Secondary reflections are caused when bright lights are facing the camera lens. These reflections can show up as spots or banding. The command adds this effect to the image by controlling their number, position, brightness and size of the spots or banding. Each lens type has its own spot distribution and ray thickness.
  • This command supports 12-bit and 16-bit grayscale and 48-bit and 64-bit color images. Support for 12-bit and 16-bit grayscale and 48-bit and 64-bit color images is available only in the Document/Medical toolkits.
  • This command does not support signed data images.

  • For an example, see the following figure:


  • The following figure shows the same image, after the effect has been applied:


  • This command does not support 32-bit grayscale images.

For more information, refer to Correcting Colors.

Lens Flare Function - Before

Lens Flare Function - Before

Lens Flare Function - After

Lens Flare Function - After

View additional platform support for this Lens Flare function.

Example

Run the LensFlareCommand on an image.

C#
using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.SpecialEffects;


public void LensFlareCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "sample5.cmp"));

   // Prepare the command
   LensFlareCommand command = new LensFlareCommand();
   //Set the center point in the middle of the first square.
   command.CenterPoint = new LeadPoint(image.Width / 4, image.Height / 4);
   command.Brightness = 100;
   command.Type = LensFlareCommandType.Type1;
   command.Color = new RasterColor(100, 150, 10);
   // Apply the lens flare effect to the image.
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}
