RasterDialogMetaFileOptions Class

Summary
Represents the Raster Meta File load options that can be used in the load process for the RasterImageFormat.Wmf, and RasterImageFormat.Emf formats, this class will be filled with File Load Options dialog options in the Resolution tap.
Syntax
C#
C++/CLI
public class RasterDialogMetaFileOptions
public ref class RasterDialogMetaFileOptions
Remarks

The Meta-File Options tab can be seen below:

Example
C#
using Leadtools;
using Leadtools.Codecs;
using Leadtools.WinForms.CommonDialogs.File;


public void RasterOpenDialogExample()
{
	RasterCodecs rasterCodecs = new RasterCodecs();

	RasterOpenDialog openDlg = new RasterOpenDialog(rasterCodecs);

	openDlg.Filter = new RasterOpenDialogLoadFormat[]
	{
	new RasterOpenDialogLoadFormat ( "All Files", "*.*" ),
	new RasterOpenDialogLoadFormat ( "LEAD", "*.cmp" )
	};

	openDlg.CheckFileExists = true;
	openDlg.CheckPathExists = true;
	openDlg.DefaultExt = "cmp";
	openDlg.DereferenceLinks = true;
	openDlg.EnableSizing = true;
	openDlg.FileName = "Image1.cmp";
	openDlg.FilterIndex = 2;
	openDlg.GenerateThumbnail = false;
	openDlg.InitialDirectory = LEAD_VARS.ImagesDir;
	openDlg.InitialView = FileDialogInitialView.List;
	openDlg.LoadCompressed = true;
	openDlg.LoadFileImage = false;
	openDlg.LoadOptions = false;
	openDlg.LoadRotated = false;
	openDlg.Multiselect = true;
	openDlg.PreviewWindowVisible = true;
	openDlg.ShowDeletePage = true;
	openDlg.ShowFileInformation = true;
	openDlg.ShowGeneralOptions = true;
	openDlg.ShowHelp = true;
	openDlg.ShowLoadCompressed = true;
	openDlg.ShowLoadOptions = true;
	openDlg.ShowLoadRotated = true;
	openDlg.ShowMultipage = true;
	openDlg.ShowPdfOptions = true;
	openDlg.ShowXpsOptions = true;
	openDlg.ShowXlsOptions = true;
	openDlg.ShowVffOptions = true;
	openDlg.ShowAnzOptions = true;
	openDlg.ShowVectorOptions = true;
	openDlg.ShowPreview = true;
	openDlg.ShowProgressive = true;
	openDlg.ShowRasterOptions = true;
	openDlg.ShowTotalPages = true;
	openDlg.Title = "Open Dialog";
	openDlg.UseFileStamptoPreview = true;
	openDlg.Help += new EventHandler<RasterDialogHelpEventArgs>(openDlg_Help);
	openDlg.LoadCorrupted = true;

	// if you set "openDlg.LoadFileImage = true" this event will be fired
	openDlg.LoadProgress += new EventHandler<RasterDialogLoadProgressEventArgs>(openDlg_LoadProgress);

	if (DialogResult.OK == openDlg.ShowDialog(null))
	{
		for (int i = 0; i < openDlg.OpenedFileData.Count; i++)
		{
			RasterDialogFileData fileDataItem = openDlg.OpenedFileData[i];

			// this is not an image file.
			if (fileDataItem.Options == null)
			{
				continue;
			}

			rasterCodecs.Options.RasterizeDocument.Load.PageWidth = fileDataItem.Options.RasterizeDocumentOptions.PageWidth;
			rasterCodecs.Options.RasterizeDocument.Load.PageHeight = fileDataItem.Options.RasterizeDocumentOptions.PageHeight;
			rasterCodecs.Options.RasterizeDocument.Load.LeftMargin = fileDataItem.Options.RasterizeDocumentOptions.LeftMargin;
			rasterCodecs.Options.RasterizeDocument.Load.TopMargin = fileDataItem.Options.RasterizeDocumentOptions.TopMargin;
			rasterCodecs.Options.RasterizeDocument.Load.RightMargin = fileDataItem.Options.RasterizeDocumentOptions.RightMargin;
			rasterCodecs.Options.RasterizeDocument.Load.BottomMargin = fileDataItem.Options.RasterizeDocumentOptions.BottomMargin;
			rasterCodecs.Options.RasterizeDocument.Load.Unit = fileDataItem.Options.RasterizeDocumentOptions.Unit;
			rasterCodecs.Options.RasterizeDocument.Load.XResolution = fileDataItem.Options.RasterizeDocumentOptions.XResolution;
			rasterCodecs.Options.RasterizeDocument.Load.YResolution = fileDataItem.Options.RasterizeDocumentOptions.YResolution;
			rasterCodecs.Options.RasterizeDocument.Load.SizeMode = fileDataItem.Options.RasterizeDocumentOptions.SizeMode;

			switch (fileDataItem.Options.FileType)
			{
				case RasterDialogFileOptionsType.Meta:
					{
						if (null != fileDataItem.Options.MetaOptions)
						{
							rasterCodecs.Options.Wmf.Load.XResolution = fileDataItem.Options.MetaOptions.XResolution;
							rasterCodecs.Options.Wmf.Load.YResolution = fileDataItem.Options.MetaOptions.XResolution;
						}
						break;
					}

				case RasterDialogFileOptionsType.Pdf:
					{
						if ((null != fileDataItem.Options.PdfOptions) &&
							  rasterCodecs.Options.Pdf.IsEngineInstalled)
						{
							rasterCodecs.Options.Pdf.Load.DisplayDepth = fileDataItem.Options.PdfOptions.DisplayDepth;
							rasterCodecs.Options.Pdf.Load.GraphicsAlpha = fileDataItem.Options.PdfOptions.GraphicsAlpha;

							if (fileDataItem.Options.PdfOptions.Password != null)
							{
								rasterCodecs.Options.Pdf.Load.Password = fileDataItem.Options.PdfOptions.Password;
							}

							rasterCodecs.Options.Pdf.Load.TextAlpha = fileDataItem.Options.PdfOptions.TextAlpha;
							rasterCodecs.Options.Pdf.Load.UseLibFonts = fileDataItem.Options.PdfOptions.UseLibFonts;
						}
						break;
					}

				case RasterDialogFileOptionsType.Misc:
					{
						if (null == fileDataItem.Options.MiscOptions)
						{
							continue;
						}

						switch (fileDataItem.FileInfo.Format)
						{
							case RasterImageFormat.Jbig:
								{
									rasterCodecs.Options.Jbig.Load.Resolution = new LeadSize(fileDataItem.Options.MiscOptions.XResolution,
									   fileDataItem.Options.MiscOptions.YResolution);
									break;
								}

							case RasterImageFormat.Cmw:
								{
									rasterCodecs.Options.Jpeg2000.Load.CmwResolution = new LeadSize(fileDataItem.Options.MiscOptions.XResolution,
									   fileDataItem.Options.MiscOptions.YResolution);
									break;
								}

							case RasterImageFormat.Jp2:
								{
									rasterCodecs.Options.Jpeg2000.Load.Jp2Resolution = new LeadSize(fileDataItem.Options.MiscOptions.XResolution,
									   fileDataItem.Options.MiscOptions.YResolution);
									break;
								}

							case RasterImageFormat.J2k:
								{
									rasterCodecs.Options.Jpeg2000.Load.J2kResolution = new LeadSize(fileDataItem.Options.MiscOptions.XResolution,
									   fileDataItem.Options.MiscOptions.YResolution);
									break;
								}
						}
						break;
					}

				case RasterDialogFileOptionsType.Xls:
					rasterCodecs.Options.Xls.Load.MultiPageSheet = fileDataItem.Options.XlsOptions.MultiPageSheet;
					rasterCodecs.Options.Xls.Load.MultiPageEnableMargins = fileDataItem.Options.XlsOptions.MultiPageEnableMargins;
					rasterCodecs.Options.Xls.Load.MultiPageUseSheetWidth = fileDataItem.Options.XlsOptions.MultiPageUseSheetWidth;
					rasterCodecs.Options.Xls.Load.PageOrderDownThenOver = fileDataItem.Options.XlsOptions.PageOrderDownThenOver;
					break;

				case RasterDialogFileOptionsType.Vff:
					rasterCodecs.Options.Vff.Load.View = fileDataItem.Options.VffOptions.View;
					break;

				case RasterDialogFileOptionsType.Anz:
					rasterCodecs.Options.Anz.Load.View = fileDataItem.Options.AnzOptions.View;
					break;

				case RasterDialogFileOptionsType.Vector:
					rasterCodecs.Options.Vector.Load.BackgroundColor = fileDataItem.Options.VectorOptions.Options.BackgroundColor;
					rasterCodecs.Options.Vector.Load.BitsPerPixel = fileDataItem.Options.VectorOptions.Options.BitsPerPixel;
					rasterCodecs.Options.Vector.Load.ForceBackgroundColor = fileDataItem.Options.VectorOptions.Options.ForceBackgroundColor;
					rasterCodecs.Options.Vector.Load.ViewHeight = fileDataItem.Options.VectorOptions.Options.ViewHeight;
					rasterCodecs.Options.Vector.Load.ViewMode = fileDataItem.Options.VectorOptions.Options.ViewMode;
					rasterCodecs.Options.Vector.Load.ViewWidth = fileDataItem.Options.VectorOptions.Options.ViewWidth;
					break;
			}

			rasterCodecs.Options.Load.Passes = fileDataItem.Passes;
			rasterCodecs.Options.Load.Rotated = fileDataItem.LoadRotated;
			rasterCodecs.Options.Load.Compressed = fileDataItem.LoadCompressed;

			RasterImage loadedImage = rasterCodecs.Load(fileDataItem.Name,
			   0,
			   CodecsLoadByteOrder.BgrOrGray,
			   fileDataItem.PageNumber,
			   fileDataItem.PageNumber);

			// COPY THE 'loadedImage' IMAGE.

			loadedImage.Dispose();
		}
	}
}
public void openDlg_Help(object sender, RasterDialogHelpEventArgs e)
{
	switch (e.Dialog)
	{
		case RasterDialogHelpName.Open:
			{
				MessageBox.Show("Open dialog Help");
				break;
			}

		case RasterDialogHelpName.LoadOptions:
			{
				MessageBox.Show("Load Options dialog Help");
				break;
			}
	}
}

public void openDlg_LoadProgress(object sender, RasterDialogLoadProgressEventArgs e)
{
	string displayText;

	displayText = "(" + e.FilePercent.ToString() + "%) of" + e.LoadRasterFileData.Name + "file is loaded";
	MessageBox.Show(displayText);

	displayText = "(" + e.TotalPercent.ToString() + "%) of all file(s) loading process is completed";
	MessageBox.Show(displayText);
}


static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS22\Resources\Images";
}
Requirements

Target Platforms
