L_AnnGetSecondaryMetafile

#include "l_bitmap.h"

L_LTANN_API L_INT L_AnnGetSecondaryMetafile(hObject, phMetafile)

HANNOBJECT hObject;	handle to the annotation object
HMETAFILE *phMetafile;	pointer to a variable to be updated with the handle to a metafile

Retrieves the metafile handle associated with an encryptor object when it is in the decryptor state.

Parameter	Description
hObject	Handle to the annotation object.
phMetafile	Pointer to a variable to be updated with the handle to a metafile.

Returns

SUCCESS	The function was successful.
< 1	An error occurred. Refer to Return Codes.

Comments

The encrypt object has two states:

Encryptor
Decryptor

Each state is displayed with its own metafile.

Use this function to retrieve the current metafile for an encrypt object in a decryptor state. The default image is shown in the figure below:

$image\decryptresized20.gif$

If this function is successful, the address pointed to by phMetafile will be updated with the metafile handle.

Use the L_AnnGetMetafile function to retrieve the current metafile for an encrypt object in an encryptor state.

Required DLLs and Libraries

LTANN

For a listing of the exact DLLs and Libraries needed, based on the toolkit version, refer to Files To Be Included With Your Application.

Platforms

Win32, x64.

Example

This example swaps the metafiles for the 'encrypt' and 'decrypt' state of an encryptor.

L_INT AnnGetSecondaryMetafileExample(HANNOBJECT hObject)
{
   L_INT nRet;
   HMETAFILE         hMetafile1=0;
   HMETAFILE         hMetafile2=0;
   L_BOOL            bEncryptorOriginal;
   ANNENCRYPTOPTIONS EncryptOptions;
   L_UINT            uObjectType;
   nRet = L_AnnGetType(hObject, &uObjectType);
   if(nRet != SUCCESS)
      return nRet;
   if (uObjectType != ANNOBJECT_ENCRYPT)
   {
      MessageBox(NULL, TEXT("This object is not an encryptor."), TEXT("Error"), MB_OK);
      return 0;
   }
   nRet = L_AnnGetMetafile(hObject, &hMetafile1);
   if(nRet != SUCCESS)
      return nRet;
   nRet = L_AnnGetSecondaryMetafile(hObject, &hMetafile2);
   if(nRet != SUCCESS)
      return nRet;
   memset(&EncryptOptions, 0, sizeof(ANNENCRYPTOPTIONS));
   EncryptOptions.uStructSize = sizeof(ANNENCRYPTOPTIONS);
   EncryptOptions.uFlags = ANNENCRYPT_ALL;
   nRet = L_AnnGetEncryptOptions(hObject,  &EncryptOptions);
   if(nRet != SUCCESS)
      return nRet;
   bEncryptorOriginal = EncryptOptions.bEncryptor;
   // Set state to encryptor, and set encryptor metafile
   EncryptOptions.uFlags      = ANNENCRYPT_TYPE;
   EncryptOptions.bEncryptor  = TRUE;
   nRet = L_AnnSetEncryptOptions(hObject, &EncryptOptions, 0);
   if(nRet != SUCCESS)
      return nRet;
   nRet = L_AnnSetMetafile(hObject, hMetafile2, ANNMETAFILE_USER, 0);
   if(nRet != SUCCESS)
      return nRet;
   // Set state to decryptor, and set decryptor metafile
   EncryptOptions.bEncryptor = FALSE;
   nRet = L_AnnSetEncryptOptions(hObject, &EncryptOptions, 0);
   if(nRet != SUCCESS)
      return nRet;
   nRet = L_AnnSetMetafile(hObject, hMetafile1, ANNMETAFILE_USER, 0);
   if(nRet != SUCCESS)
      return nRet;
   // Set encryptor to oringal state
   EncryptOptions.bEncryptor = bEncryptorOriginal;
   nRet = L_AnnSetEncryptOptions(hObject, &EncryptOptions, 0);
   if(nRet != SUCCESS)
      return nRet;
   return SUCCESS;
}
