MicroQR Barcode in LEADTOOLS

Micro QR Code is a two-dimensional barcode based on the popular QR Code. By dropping two of the three position detection patterns of its predecessor, Micro QR Codes are able to be printed at a fraction of the size while still encoding a relatively substantial amount of data.

Sample Barcode

Symbology
BarcodeSymbology.MicroQR
MicroQR
Micro QR Codes have four versions corresponding to sizes and error correction levels, the maximum of which can encode up to 15 bytes, 21 alphanumeric, or 35 numeric digits.

Barcode Support

Data Options Member
LEADTOOLS Symbology Identifier BarcodeSymbology.MicroQR
Data Class MicroQRBarcodeData
Read Options MicroQRBarcodeReadOptions
Write Options MicroQRBarcodeWriteOptions

Features

Information for Writing MicroQR Barcodes with LEADTOOLS

The Micro QR standard specifies 4 different sizes for the Micro QR barcode. The maximum data capacity varies, depending on the size of the barcode and its Error Correction level. The following table contains information for writing 2D Micro QR barcodes:

Model - Error Correction Level
MicroQRBarcodeSymbolModel
Modules Data Bits Numeric Alphanumeric Binary Kanji
M1 11x11 20 5 - - -
M2 - L 13x13 40 10 6 - -
M2 - M 13x13 32 8 5 - -
M3 - L 15x15 84 23 14 9 6
M3 - M 15x15 68 18 11 7 4
M4 - L 17x17 128 35 21 15 9
M4 - M 17x17 112 30 18 13 8
M4 - Q 17x17 80 21 13 9 5
