2 of 5 Barcodes in LEADTOOLS

LEADTOOLS 1D Barcode SDK supports all the major 2 of 5 barcode symbologies employed throughout the world in various industries.

Standard / Industrial / Airline 2 of 5

Two-out-of-five, or 2 of 5, is an error detection and correction technique that uses two bits out of five and provides exactly ten combinations. Therefore, it is perfectly suited for encoding the numerals 0-9 and can easily be incorporated into barcodes by using wide and narrow bars representing the on and off bits.

Sample Barcode

Symbology
BarcodeSymbology.CodeStandard2Of5
CodeStandard2Of5
Standard 2 of 5, also known as Industrial 2 of 5, was developed in the 1960's and is used widely in the airline ticketing, photofinishing, and warehouse industries.

Barcode Support

Data Options Member
LEADTOOLS Symbology Identifier BarcodeSymbology.CodeStandard2Of5
Data Class BarcodeData
Read Options OneDBarcodeReadOptions
Write Options OneDBarcodeWriteOptions

ITF / Interleaved Two of Five / Interleaved 2 of 5

The ITF symbology is similar to the Standard 2 of 5, except that with ITF data can be stored in both the width of the bars and spaces; whereas with Standard 2 of 5 data can only be stored in the width of the bars.

Sample Barcode

Symbology
BarcodeSymbology.CodeInterleaved2Of5
CodeInterleaved2Of5
ITF is used widely in the shipping industry as it is especially suited to be printed directly onto packaging materials with poor printing quality such as corrugated cardboard. ITF can also be used to store EAN data structures.

Barcode Support

Data Options Member
LEADTOOLS Symbology Identifier BarcodeSymbology.CodeInterleaved2Of5
Data Class BarcodeData
Read Options OneDBarcodeReadOptions
Write Options OneDBarcodeWriteOptions
