Options Property

Summary
Gets the options being used to read the symbologies.
Syntax
C#
Objective-C
C++/CLI
Java
Python
public BarcodeReadOptions Options { get; }
@property (nonatomic, strong, readonly, nullable) LTBarcodeReadOptions *options
public BarcodeReadOptions getOptions()
public:
property BarcodeReadOptions^ Options {
   BarcodeReadOptions^ get();
}

Property Value

An BarcodeReadOptions or one of its derived classes that specifies the options being used to read the symbologies.

Remarks

Options could be the options passed through the read methods or the default options set in BarcodeReader. If Status is BarcodeReadSymbologyStatus.PreRead, then you can modify this object in the event handler if required. The BarcodeReader will use this object to perform the read operation.

Example
C#
using Leadtools;
using Leadtools.Codecs;
using Leadtools.Barcode;
using Leadtools.ImageProcessing;


public void BarcodeReader_ReadSymbologyExample()
{
   string imageFileName = Path.Combine(LEAD_VARS.ImagesDir, "Barcode1.tif");

   // Create a Barcode engine
   BarcodeEngine engine = new BarcodeEngine();

   // Get the Barcode reader instance
   BarcodeReader reader = engine.Reader;

   // Load the image
   using (RasterCodecs codecs = new RasterCodecs())
   {
      using (RasterImage image = codecs.Load(imageFileName, 0, CodecsLoadByteOrder.BgrOrGray, 1, 1))
      {
         // Subscribe to the ReadSymbology event
         reader.ReadSymbology += new EventHandler<BarcodeReadSymbologyEventArgs>(reader_ReadSymbology);
         // Read all barcodes in the image
         reader.ReadBarcodes(image, LeadRect.Empty, 0, null);
         reader.ReadSymbology -= new EventHandler<BarcodeReadSymbologyEventArgs>(reader_ReadSymbology);
      }
   }
}

private void reader_ReadSymbology(object sender, BarcodeReadSymbologyEventArgs e)
{
   if (e.Operation == BarcodeReadSymbologyOperation.PreRead)
   {
      // Before reading, show the symbologies the engine is going to try to read
      Console.WriteLine("Trying to read the following symbologies:");
      BarcodeSymbology[] symbologies = e.GetSymbologies();
      for (int i = 0; i < symbologies.Length; i++)
      {
         Console.Write(symbologies[i]);
         if (i != (symbologies.Length - 1))
         {
            Console.Write(", ");
            Console.WriteLine(e.Options.FriendlyName);
         }
         else
         {
            Console.WriteLine();
         }
      }
   }
   else if (e.Operation == BarcodeReadSymbologyOperation.PostRead)
   {
      if (e.Error == null)
      {
         // No errors
         BarcodeData barcode = e.Data;
         if (barcode != null)
         {
            // Found a barcode, show it
            Console.WriteLine("  {0} at {1} with data {2}", barcode.Symbology, barcode.Bounds, barcode.Value);
         }
         else
         {
            Console.WriteLine("  No barcodes found");
         }
      }
      else
      {
         // Show the error
         Console.WriteLine("Error: {0}", e.Error.Message);

         // Tell the reader top stop reading barcodes
         e.Status = BarcodeReadSymbologyStatus.Abort;
      }
   }
}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS22\Resources\Images";
}
