InvertedTextCommand Class

Summary
Finds and modifies areas of inverted text in a 1-bit black and white image.
Syntax
C#
Objective-C
C++/CLI
Java
Python
public class InvertedTextCommand : RasterCommand
@interface LTInvertedTextCommand : LTRasterCommand
public class InvertedTextCommand
    extends RasterCommand
public ref class InvertedTextCommand : public RasterCommand
class InvertedTextCommand(RasterCommand):
Remarks

This command is available in the Document/Medical Toolkits.

  • This command finds and modifies areas of inverted text that are common in scanned text documents. Below is an example of inverted text:

    Modifying the area of inverted text yields the following:
  • The behavior of this command can be modified by using an Event Handler that handles the InvertedTextCommandEventArgs.

  • This command works only on 1-bit black and white images.
  • If a region is selected, only the selected region will be changed by this method. If no region is selected, the whole image will be processed.
  • This command does not support signed data images.
  • This command does not support 32-bit grayscale images.

For more information, refer to Cleaning Up 1-Bit Images.

Inverted Text Function - Before

Inverted Text Function - Before

Inverted Text Function - After

Inverted Text Function - After

View additional platform support for this Inverted Text function.

Example

Runs the InvertedTextCommand on an image.

C#
Java
using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Core;

public void InvertedTextCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "Clean.tif"));

   // Prepare the command
   InvertedTextCommand command = new InvertedTextCommand();
   command.InvertedText += new EventHandler<InvertedTextCommandEventArgs>(InvertedTextEvent_S1);
   command.Flags = InvertedTextCommandFlags.UseDpi;
   command.MaximumBlackPercent = 95;
   command.MinimumBlackPercent = 70;
   command.MinimumInvertHeight = 500;
   command.MinimumInvertWidth = 5000;

   command.Run(image);

}

private void InvertedTextEvent_S1(object sender, InvertedTextCommandEventArgs e)
{

   MessageBox.Show("Size " + "( " + e.BoundingRectangle.Left + ", " + e.BoundingRectangle.Top + ") - " + "( " + e.BoundingRectangle.Right + ", " + e.BoundingRectangle.Bottom + ")" +
      "\n Black Count " + e.BlackCount.ToString() +
      "\n White Count " + e.WhiteCount.ToString());
   e.Status = RemoveStatus.Remove;
}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}

import java.io.File;
import java.io.IOException;

import org.junit.*;
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
import static org.junit.Assert.*;

import leadtools.*;
import leadtools.codecs.*;
import leadtools.imageprocessing.core.*;


public void invertedTextCommandExample() {
    final String LEAD_VARS_IMAGES_DIR = "C:\\LEADTOOLS23\\Resources\\Images";

    // Load an image
    RasterCodecs codecs = new RasterCodecs();
    codecs.setThrowExceptionsOnInvalidImages(true);

    RasterImage image = codecs.load(combine(LEAD_VARS_IMAGES_DIR, "Clean.tif"));

    // Prepare the command
    InvertedTextCommand command = new InvertedTextCommand();
    command.addInvertedTextCommandListener(invertedTextEvent_S1);
    command.setFlags(InvertedTextCommandFlags.USE_DPI.getValue());
    command.setMaximumBlackPercent(95);
    command.setMinimumBlackPercent(70);
    command.setMinimumInvertHeight(500);
    command.setMinimumInvertWidth(5000);

    command.run(image);
    codecs.save(image, combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"), RasterImageFormat.JPEG, 24);

    assertTrue(new File(combine(LEAD_VARS_IMAGES_DIR, "Result.jpg")).exists());
    System.out.println("Command run and image saved to " + combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"));
}

InvertedTextCommandListener invertedTextEvent_S1 = new InvertedTextCommandListener() {
    @Override
    public void onInvertedTextEvent(InvertedTextCommandEvent e) {
        System.out.println(
                "Size ( " + e.getBoundingRectangle().getLeft() + ", " + e.getBoundingRectangle().getTop() + ") - "
                        + "( "
                        + e.getBoundingRectangle().getRight() + ", " + e.getBoundingRectangle().getBottom() + ")" +
                        "\n Black Count " + e.getBlackCount() +
                        "\n White Count " + e.getWhiteCount());
        e.setStatus(RemoveStatus.REMOVE);
    }
};
Requirements
