GS1 DataBar/RSS Barcode SDK Technology

LEADTOOLS provides fast, highly accurate, and reliable GS1 DataBar/RSS-14 Barcode detection, reading, and writing support for .NET (C# & VB, Core, Xamarin, UWP), C/C++, iOS, macOS, Linux, Java, and web developers. LEADTOOLS award-winning libraries help programmers add fully featured GS1 DataBar/RSS-14 Barcode technology to applications in record time.

GS1 DataBar, formerly known as Reduced Space Symbology (RSS), is a large family of barcodes that encode a GTIN-12 or GTIN-13 data structure within a 14 digit barcode. The various GS1 DataBar symbols have specific features that allow them to be read by different types of scanners and be used in a variety of industries, including retail point-of-sale applications, inventory tracking, and health care.

LEADTOOLS GS1 DataBar/RSS-14 Barcode SDK Symbols

Symbols intended for retail point-of-sale scanning

  • GS1 DataBar (DataBar-14)
  • GS1 DataBar Stacked Omni-directional (DataBar-14 Stacked Omni-directional)
  • GS1 DataBar Expanded
  • GS1 DataBar Expanded Stacked

Symbols that are not intended for retail point-of-sale scanning

  • GS1 DataBar Truncated (DataBar-14 Truncated)
  • GS1 DataBar Limited
  • GS1 DataBar Stacked

GS1 DataBar Omni-directional/RSS-14 Omni-directional

Databar Barcode

GS1 DataBar Omni-directional encodes the full 14-digit EAN.UCC item identification in a linear symbol that can be scanned omni-directionally by suitably programmed point-of-sale scanners. It was developed to increase the number of unique codes and to meet the needs of encoding more information into smaller space.

GS1 DataBar Truncated/RSS-14 Truncated

The GS1 DataBar Truncated has the exact same data characteristics as the GS1 DataBar barcode, except the bar height is set to the GS1 DataBar standard of 13 times the X dimension. GS1 DataBar Truncated is designed to be scanned by wands, linear scanners, and hand-held lasers. It cannot be scanned efficiently by omni-directional scanners.

GS1 DataBar Stacked/RSS-14 Stacked

Databar Stacked Barcode

RSS-14 Stacked is a variation of the RSS-14 symbology that is stacked in two rows and is used when the normal symbol would be too wide for the application. It is used for small item marking applications and is designed to be scanned by wands, linear scanners, and hand-held lasers. It cannot be scanned efficiently by omni-directional scanners.

GS1 DataBar Stacked Omni-directional/RSS-14 Stacked Omni-directional

The GS1 DataBar Stacked Omni-directional can be scanned omni-directionally. This symbology does not allow for human readable text with the barcode. The data to encode is separated to create a split-level barcode. The height of each row is ascertained from the bar height property of the control. The barcode contains a separator pattern, containing no data, which has a height equal to 3 times the X dimension.

GS1 DataBar Limited/RSS-14 Limited

Databar Limited Barcode

The GS1 DataBar Limited encodes a 14-digit EAN.UCC item identification with indicator digits of zero or one in a linear symbol for use on small items that will not be scanned at the point of sale.

GS1 DataBar Expanded/RSS-14 Expanded

Databar Expanded Barcode

GS1 DataBar Expanded encodes EAN.UCC item identification plus supplementary AI element strings such as weight and "best before" date in a linear symbol that can be scanned omni-directionally by suitably programmed point-of-sale scanners.

GS1 DataBar Expanded Stacked/RSS-14 Expanded Stacked

Databar Expanded Stacked Barcode

GS1 DataBar Expanded Stacked is a variation of the RSS-14 Expanded symbology that is stacked into multiple rows and is used when the normal symbol would be too wide for the application.

Other Types of Linear 1D Barcodes

Technology Related to GS1 DataBar/RSS Barcode

Start Coding with LEADTOOLS

Download the Full Evaluation

The Full Evaluation Download includes all LEADTOOLS Document, Medical, Imaging, and Vector technologies for all development and target platforms. Get everything LEADTOOLS all in one convenient download.

Download Projects using NuGet

LEADTOOLS provides NuGet packages for .NET Framework, .NET Core, UWP, and Xamarin development. Download projects that reference our NuGets and start coding right away.

Supported Development Platforms for GS1 DataBar/RSS Barcode

Documentation Links for GS1 DataBar/RSS Barcode

White Papers Written About GS1 DataBar/RSS Barcode

  • Choosing the Right Barcode for Your Application

    For many of us, a day hardly goes by without seeing a barcode. For software developers, this creates immense opportunities to create software that handles both the encoding and decoding of barcodes. How does a developer or project manager get started on their path to success? When you boil it down, there are two primary questions you should ask: Which barcodes should I use? How will I use them? This white paper will help clear the muddied waters surrounding both of these questions by detailing several of the most popular barcodes and how programmers can use the award winning imaging SDK technology in LEADTOOLS to quickly and easily develop their application.

Demo Applications that Include GS1 DataBar/RSS Barcode

HTML5/JavaScript Barcode Reader

Uses HTML5 and JavaScript to demonstrate our barcode technology reading 34 different barcode symbologies in various test and real-world images.

Screenshots of GS1 DataBar/RSS Barcode

GS1 Databar Barcode

GS1 Databar Barcode

LEADTOOLS SDK Products that Include GS1 DataBar/RSS Barcode

LEADTOOLS Barcode Pro v20

LEADTOOLS Barcode Pro includes everything developers need to detect, read, and write over 100 different 1D and 2D barcode types and sub-types such as UPC, EAN, Code 128, QR Code, Data Matrix, and PDF417. By building upon the award-winning LEADTOOLS Imaging Pro features, including 150+ image formats, image compression, image processing, image viewers, imaging common dialogs, 200+ display effects, TWAIN and WIA scanning, screen capture, and printing, LEADTOOLS Barcode Pro is one of the best values on the market for barcode imaging technology.

LEADTOOLS Pro Suite v20

LEADTOOLS Pro Suite is a an extensive bundle in the LEADTOOLS Pro line of SDKs and includes HTML5 Zero-footprint image viewers, barcode detect/read/write, advanced PDF read/write/view/edit, 150+ image formats, image compression, image processing, image viewers, imaging common dialogs, 200+ display effects, TWAIN and WIA scanning, screen capture, and printing. Developers using LEADTOOLS Pro Suite can develop robust imaging applications and solutions at a fraction of the cost of similar feature sets found elsewhere on the market.

LEADTOOLS Document Imaging v20

Develop powerful document imaging applications with LEADTOOLS Document Imaging. Features include PDF viewing and editing, comprehensive image annotating, specialized bitonal image displaying, and image processing. Other features include performance and memory optimizations for bitonal images, document image cleanup, including inverted text, border, hole-punch, and line removal, and scanning with LEADTOOLS Fast TWAIN and WIA.

LEADTOOLS Recognition v20

The LEADTOOLS Recognition Imaging SDK is a handpicked collection of LEADTOOLS SDK features designed to build end-to-end document imaging applications within enterprise-level document automation solutions that require OCR, MICR, OMR, barcode, forms recognition and processing, PDF, print capture, archival, annotation, and image viewing functionality. This powerful set of tools utilizes LEAD's award-winning image processing technology to intelligently identify document features that can be used to recognize and extract data from any type of scanned or faxed form image.

LEADTOOLS Document Imaging Suite v20

The LEADTOOLS Document Imaging Suite SDK is a comprehensive collection of LEADTOOLS SDK features designed to build end-to-end document imaging solutions that require OCR, MICR, OMR, ICR, barcode, forms recognition and processing, PDF, HTML5 Zero-footprint viewing, conversion, print, capture, archival, annotation, and image viewing functionality. This powerful set of tools utilizes LEAD's award-winning image processing technology to intelligently identify document features that can be used to recognize and extract data from any type of scanned or faxed form image.

LEADTOOLS Medical Imaging v20

Develop powerful Medical Imaging applications with the LEADTOOLS Medical Imaging SDK. Features include comprehensive DICOM data set support, 8-16 bit extended grayscale image support, image annotation, specialized extended grayscale image display such as window level and LUT processing, and medical-specific image processing. Other features include lossless JPEG compression, and signed and unsigned image data processing.

LEADTOOLS PACS Imaging v20

Develop robust DICOM PACS applications with LEADTOOLS PACS Imaging. Features include Medical Web Viewer Framework, high and low-level PACS SCP and SCU functions and controls, secure PACS communication, comprehensive DICOM data set support, image annotation, extended grayscale image display such as window level and LUT processing, and specialized medical image processing. Other features include lossless JPEG compression, JPIP, MRTI, and signed and unsigned image data processing.

LEADTOOLS Medical Imaging Suite v20

Develop powerful PACS and Medical imaging applications with LEADTOOLS Medical Imaging Suite. Features include LEAD's Zero-footprint HTML5 DICOM Viewer, Medical Web Viewer Framework, Medical 3D, DICOM Multimedia codecs, high and low-level PACS SCP and SCU functions and controls, secure PACS communication, Print to PACS, comprehensive DICOM data set support, image annotation, extended grayscale image display such as window level and LUT processing, DICOM Hanging Protocol, and specialized medical image processing. Other features include lossless JPEG compression, JPIP, and signed and unsigned image data processing.
