←Select platform

MultiplyCommand Class

Summary
Increases or decreases the brightness in the image by multiplying the colors in a specific image by a factoring value divided by 100.
Syntax
C#
Objective-C
C++/CLI
Java
Python
public class MultiplyCommand : RasterCommand
@interface LTMultiplyCommand : LTRasterCommand
public class MultiplyCommand
    extends RasterCommand
public ref class MultiplyCommand : public RasterCommand
class MultiplyCommand(RasterCommand):
Remarks
  • This class is used to increase or decrease the brightness in the image by multiplying the colors in a specific image by a factoring value divided by 100. For example, if the factoring value is 131, the colors in the image will be multiplied by 1.31.
  • This class supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
  • This command does not support 32-bit grayscale images.

If the image has a LUT and you want to work on the image data, set RasterImage.UseLookupTable to false. Then, after calling the method, reset the UselookupTable property to true, as follows:

rasterImage.UseLookupTable = false;
Method(rasterImage);
rasterImage.UseLookupTable = true;

For more information, refer to Changing Brightness and Contrast.

Multiply Function - Before

Multiply Function - Before

Multiply Function - After

Multiply Function - After

View additional platform support for this Multiply function.

Example

Run the MultiplyCommand on an image with factor = 1.51.

C#
Java
using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Color;


public void MultiplyCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "IMAGE1.CMP"));

   // Prepare the command
   MultiplyCommand command = new MultiplyCommand();
   command.Factor = 151;
   // Multiply the colors of the bitmap with 1.51.
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}

import java.io.File;
import java.io.IOException;

import org.junit.*;
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
import static org.junit.Assert.*;

import leadtools.*;
import leadtools.codecs.*;
import leadtools.imageprocessing.color.MultiplyCommand;


public void multiplyCommandExample() {
   final String LEAD_VARS_IMAGES_DIR = "C:\\LEADTOOLS23\\Resources\\Images";

   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.setThrowExceptionsOnInvalidImages(true);

   RasterImage image = codecs.load(combine(LEAD_VARS_IMAGES_DIR, "IMAGE1.CMP"));

   // Prepare the command
   MultiplyCommand command = new MultiplyCommand();
   command.setFactor(151);
   assertTrue(command.getFactor() == 151);
   // Multiply the colors of the bitmap with 1.51.
   command.run(image);
   codecs.save(image, combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"), RasterImageFormat.JPEG, 24);

   System.out.println("Command run and image saved to " + combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"));
   assertTrue(new File(combine(LEAD_VARS_IMAGES_DIR, "Result.jpg")).exists());
}
Requirements

Target Platforms

Help Version 23.0.2024.3.3
