LBitmap::LensFlare

#include "ltwrappr.h"

virtual L_INT LBitmap::LensFlare(ptCenter, uBright, uFlag, crColor)

POINT ptCenter;

/* effect center point */

L_UINT uBright;

/* brightness factor */

L_UINT uFlag;

/* flag */

COLORREF crColor;

/* color value */

Simulates the secondary reflections caused when bright lights are facing the camera lens. The lens flare is refracted into a series of lightened circles that surround the flare. This function is available in the Raster Pro and above toolkits.

Parameter

Description

ptCenter

POINT structure that contains the point around which the effect is centered.

uBright

The brightness of the flare. This value is divided internally by 100. This parameter affects the brightness of both the flare, and any lightened circles surrounding the flare.

uFlag

Flag that indicates the lens type. Possible values are:



Value

Meaning



LNS_TYPE_1

[0x0000] Standard lens



LNS_TYPE_2

[0x0001] Moderate wide-angle lens



LNS_TYPE_3

[0x0002] Moderate telephoto lens

crColor

The COLORREF value that represents the color of the main flare.

Returns

SUCCESS

The function was successful.

< 1

An error occurred. Refer to Return Codes.

Comments

Secondary reflections are caused when bright lights are facing the camera lens. These reflections can show up as spots or banding. The function adds this effect to the bitmap by controlling their number, position, brightness and size of the spots or banding. Each lens type has its own spot distribution and ray thickness.

This function supports 12- and 16-bit grayscale and 48- and 64-bit color images. Support for 12- and 16-bit grayscale and 48- and 64-bit color images is available only in the Document/Medical toolkits.

To update a status bar or detect a user interrupt during execution of this function, refer to LBase::EnableStatusCallback.

For an example, see the following figure:


The following figure shows the same bitmap, after the effect has been applied:


To obtain this effect, the following settings were used with the function:

ptCenter = (150, 162);

uBright = 100;

uFlag = LNS_TYPE_1;

crColor = RGB(255,128,0);

This function does not support signed data images. It returns the error code ERROR_SIGNED_DATA_NOT_SUPPORTED if a signed data image is passed to this function.

Required DLLs and Libraries

LTIMG

For a listing of the exact DLLs and Libraries needed, based on the toolkit version, refer to Files To Be Included With Your Application.

See Also

Functions:

LBitmap::AdjustTint. LBitmap::ColorHalfTone, LBitmap::BricksTexture, LBitmap::Canvas, LBitmap::Clouds, LBitmap::ColoredBalls, LBitmap::DiffuseGlow, LBitmap::DisplaceMap, LBitmap::Fragment, LBitmap::HalfTonePattern, LBitmap::MaskConvolution, LBitmap::MosaicTiles, LBitmap::Offset, LBitmap::Perspective, LBitmap::PlasmaFilter, LBitmap::Pointillist, LBitmap::RomanMosaic, LBitmap::Vignette, LBitmap::ZigZag, LBitmap::AddNoise, LBitmap::Emboss, LBitmap::Mosaic, LBitmap::MotionBlur, LBitmap::Oilify, LBitmap::Posterize, LBitmap::RemoveRedeye, LBitmap::Solarize, LBitmapBase::Underlay, LBitmap::BumpMap, LBitmap::Cubism, LBitmap::DrawStar, LBitmap::Dry, LBitmap::FreePlaneBend, LBitmap::FreeRadBend, LBitmap::GlassEffect, LBitmap::GlowFilter, LBitmap::LensFlare, LBitmap::Light, LBitmap::Ocean, LBitmap::PlaneBend, LBitmap::Plane, LBitmap::SampleTarget, LBitmap::Tunnel, LBitmap::Bending, LBitmap::Cylindrical, LBitmap::FreeHandShear, LBitmap::FreeHandWave, LBitmap::Impressionist, LBitmap::Pixelate, LBitmap::Polar, LBitmap::Punch, LBitmap::RadialBlur, LBitmap::RadWave, LBitmap::Ripple, LBitmap::Spherize, LBitmap::Swirl, LBitmap::Wave, LBitmap::Wind, LBitmap::ZoomBlur, LBitmap::ZoomWave

Topics:

Raster Image Functions: Artistic Effects



Raster Image Functions: Modifying Intensity Values



Applying Artistic Effects



Using Color Values in LEADTOOLS



Raster Image Functions: Correcting Colors

Example

void TestFunction(LAnimationWindow *BitmapWindow)
{
   POINT  CenterPt;
   CenterPt.x  =  BitmapWindow->GetWidth()/2;
   CenterPt.y  =  BitmapWindow->GetHeight()/2;

   BitmapWindow->LensFlare(CenterPt, 100, LNS_TYPE_1,  RGB(100, 150, 10));
}
