ScreenCaptureEngine Class

Imports Leadtools
Imports Leadtools.Codecs
Imports Leadtools.ScreenCapture

WithEvents scEngine As ScreenCaptureEngine
Public Sub ScreenCaptureEngineExample()
   ' Startup the ScreenCapture
   ScreenCaptureEngine.Startup()

   ' Define a ScreenCaptureEngine class object
   scEngine = New ScreenCaptureEngine()

   ' Define the Help Callback that will run whenever the Help button is pressed on the dialogs
   Dim helpCallbackObj As New ScreenCaptureHelpCallback(AddressOf HelpCallback)

   ' Define ScreenCaptureAreaOptions and fill it using dialog
   Dim scAreaOptions As ScreenCaptureAreaOptions
   scAreaOptions = ScreenCaptureAreaOptions.Empty

   ' Get the default options
   scAreaOptions = ScreenCaptureEngine.DefaultCaptureAreaOptions

   ' Open the dialog allowing the user to change the values
   ' NOTE: To fill the structure manually, you can write:
   ' Cursor drawCursor = Cursors.Cross;
   ' scAreaOptions.AreaType = ScreenCaptureAreaType.Rectangle;
   ' scAreaOptions.DrawCursor = drawCursor;
   ' scAreaOptions.DrawLineColor = Color.Red;
   ' scAreaOptions.DrawLineStyle = ScreenCaptureAreaLineStyle.Solid;
   ' scAreaOptions.EllipseHeight = 0;
   ' scAreaOptions.EllipseWidth = 0;
   ' scAreaOptions.FillBackgroundColor = Color.Black;
   ' scAreaOptions.FillForegroundColor = Color.White;
   ' scAreaOptions.FillPattern = ScreenCaptureAreaFillPattern.Solid;
   ' scAreaOptions.Flags = ScreenCaptureAreaFlags.ShowInfoWindow;
   ' scAreaOptions.InfoWindowBounds = new Rectangle(ScreenCaptureAreaOptions.LeftInfoWindowPosition, ScreenCaptureAreaOptions.TopInfoWindowPosition,_
   ' ScreenCaptureAreaOptions.MediumInfoWindowSize, ScreenCaptureAreaOptions.MediumInfoWindowSize);
   ' scAreaOptions.TextBackgroundColor = Color.White;
   ' scAreaOptions.TextForegroundColor = Color.Black;
   ' scAreaOptions.Zoom = ScreenCaptureAreaZoom.Normal;
   scEngine.ShowCaptureAreaOptionsDialog(Nothing, ScreenCaptureDialogFlags.CaptureAreaOptionsContextHelp, scAreaOptions, True, helpCallbackObj)

   ' Define ScreenCaptureOptions and fill it using dialog
   Dim scOptions As ScreenCaptureOptions
   scOptions = ScreenCaptureOptions.Empty

   ' Set the ScreenCaptureHotKeyCallback, so that it gets called if the hotkey is set in the dialog
   Dim hotkeyCallbackObj As New ScreenCaptureHotkeyCallback(AddressOf HotKeyCallback)
   ScreenCaptureEngine.SetCaptureHotkeyCallback(hotkeyCallbackObj)

   ' Open the dialog allowing the user to change the values
   ' NOTE: To fill the structure manually, you can write:
   ' scOptions.CancelKey = Keys.Escape;
   ' scOptions.Count = 1;
   ' scOptions.Cursor = Cursors.Arrow;
   ' scOptions.Delay = 0;
   ' scOptions.Hotkey = Keys.F11;
   ' scOptions.Interval = 0;
   ' scOptions.OptimizedHotkey = true;
   ' scOptions.StatusCursor = Cursors.WaitCursor;
   scEngine.ShowCaptureOptionsDialog(Nothing, ScreenCaptureDialogFlags.SetCaptureOptionsContextHelp, scOptions, helpCallbackObj)

   ' Set the Engine's ScreenCaptureOptions
   scEngine.CaptureOptions = scOptions

   ' Define ScreenCaptureObjectOptions and fill it using dialog
   Dim scObjectOptions As ScreenCaptureObjectOptions
   scObjectOptions = ScreenCaptureObjectOptions.Empty

   ' Get the default Options
   scObjectOptions = ScreenCaptureEngine.DefaultCaptureObjectOptions

   ' Open the dialog allowing the user to change the values
   ' NOTE: To fill the structure manually, you can write:
   ' scObjectOptions.BorderWidth = 2;
   ' scObjectOptions.EnableKeyboard = true;
   ' scObjectOptions.Invert = false;
   ' scObjectOptions.SelectCursor = Cursors.Arrow;
   scEngine.ShowCaptureObjectOptionsDialog(Nothing, ScreenCaptureDialogFlags.CaptureObjectOptionsContextHelp, scObjectOptions, True, helpCallbackObj)

   ' Define ScreenCaptureInformation class object
   Dim scInformation As ScreenCaptureInformation = Nothing

   ' NOTE: After preparing the structures and classes,
   ' in this place you can insert any Capture method, such as:
   ' CaptureWindow, CaptureActiveWindow, CaptureActiveClient, CaptureWallpaper,
   ' CaptureFullScreen, CaptureMenuUnderCursor, CaptureWindowUnderCursor,
   ' CaptureSelectedObject, CaptureArea, CaptureMouseCursor

   ' We will Capture an Area of the screen
   Dim image As RasterImage
   image = scEngine.CaptureArea(scAreaOptions, scInformation)

   ' To get the number of resources in a EXE file
   Dim iconsCount As Integer

   iconsCount = scEngine.GetResourcesCount(Path.Combine(LEAD_VARS.ImagesDir, "ExeWithResources.exe"), ScreenCaptureResourceType.Icon)

     ' Finally, if the Capture is still active, then Stop it
     If (scEngine.IsCaptureActive) Then
         scEngine.StopCapture()
     End If

     ' clean up
     image.Dispose()

     ' Shutdown the ScreenCapture
     ScreenCaptureEngine.Shutdown()
 End Sub

 Public Function HotKeyCallback(ByVal key As Keys) As Boolean
     ' Here you can do anything with the pressed key
     ' we will just show a message box
     MessageBox.Show("You pressed the " + key.ToString() + "character.")

     Return True
 End Function

 Public Sub HelpCallback(ByVal helpType As ScreenCaptureHelpType, ByVal controlId As ScreenCaptureControlId)
     ' Show a MessageBox mentioning the name of the dialog that called the help,
     ' and which control ID was requested.
     Select Case (helpType)
         Case ScreenCaptureHelpType.CaptureAreaOptions
             MessageBox.Show("Capture Area Options Dialog Help Button" & Environment.NewLine & "Control Id: " & controlId.ToString() & ".")
         Case ScreenCaptureHelpType.CaptureFromExe
             MessageBox.Show("Capture From EXE Dialog Help Button" & Environment.NewLine & "Control Id: " & controlId.ToString() & ".")
         Case ScreenCaptureHelpType.CaptureObjectOptions
             MessageBox.Show("Capture Object Options Dialog Help Button" & Environment.NewLine & "Control Id: " & controlId.ToString() & ".")
         Case ScreenCaptureHelpType.SetCaptureOptions
             MessageBox.Show("Capture Options Dialog Help Button" & Environment.NewLine & "Control Id: " & controlId.ToString() & ".")
         Case Else
             ' will never reach here
     End Select
 End Sub

 Public Sub scEngine_CaptureInformation(ByVal sender As Object, ByVal e As ScreenCaptureInformationEventArgs) Handles scEngine.CaptureInformation

     ' Define codecs class object to save the image
     Dim codecs As New RasterCodecs()
     codecs.ThrowExceptionsOnInvalidImages = True

     ' Save the resulted Image
   codecs.Save(e.Image, Path.Combine(LEAD_VARS.ImagesDir, "CapturedImage.bmp"), RasterImageFormat.Bmp, 24)


     ' NOTE: e.Information is a ScreenCaptureInformation structure filled with information
     ' about the captured image, this information can be used here
     ' Display a MessageBox with the bounds of the capture area
   MessageBox.Show("Captured Area Bounds:" & Environment.NewLine & "Top:" & e.Information.Area.Top.ToString() & Environment.NewLine & _
                   "Left:" & e.Information.Area.Left.ToString() & Environment.NewLine & "Right:" + e.Information.Area.Right.ToString() & _
                   Environment.NewLine & "Bottom:" & e.Information.Area.Bottom.ToString())

     ' everything worked fine
     e.Cancel = False
 End Sub

Public NotInheritable Class LEAD_VARS
Public Const ImagesDir As String = "C:\Users\Public\Documents\LEADTOOLS Images"
End Class
