AnnCurveObject Class

Visual Basic
C#
Objective-C
Java
C++

[SerializableAttribute()]
public class AnnCurveObject : AnnPolylineObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Declaration

<SerializableAttribute()>
Public Class AnnCurveObject
   Inherits AnnPolylineObject
   Implements System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Usage

Dim instance As AnnCurveObject

[SerializableAttribute()]
public ref class AnnCurveObject : public AnnPolylineObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

The curve object is a spline curve that contains a collection of AnnPoint points, a Tension value and an AnnPen pen. For more information about the curve annotation object refer to AnnCurveObject. For more information about the automated curve annotation object, refer to Annotation Objects - Automated Features.

Visual Basic
C#
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Copy Code

Imports Leadtools
Imports Leadtools.Annotations
Imports Leadtools.Codecs
Imports Leadtools.WinForms

Private Sub AnnCurveObject_AnnCurveObject(ByVal container As AnnContainer)
   Dim curve As AnnCurveObject = New AnnCurveObject()
   curve.Points.Add(New AnnPoint(100, 100, AnnUnit.Pixel))
   curve.Points.Add(New AnnPoint(200, 100, AnnUnit.Pixel))
   curve.Points.Add(New AnnPoint(200, 200, AnnUnit.Pixel))
   curve.Points.Add(New AnnPoint(100, 300, AnnUnit.Pixel))
   curve.Pen = New AnnPen(Color.Red, New AnnLength(1, AnnUnit.Pixel))
   curve.Tension = 1
   container.Objects.Add(curve)
End Sub

using Leadtools;
using Leadtools.Annotations;
using Leadtools.Codecs;
using Leadtools.WinForms;

private void AnnCurveObject_AnnCurveObject(AnnContainer container)
{
   AnnCurveObject curve = new AnnCurveObject();
   curve.Points.Add(new AnnPoint(100, 100, AnnUnit.Pixel));
   curve.Points.Add(new AnnPoint(200, 100, AnnUnit.Pixel));
   curve.Points.Add(new AnnPoint(200, 200, AnnUnit.Pixel));
   curve.Points.Add(new AnnPoint(100, 300, AnnUnit.Pixel));
   curve.Pen = new AnnPen(Color.Red, new AnnLength(1, AnnUnit.Pixel));
   curve.Tension = 1;
   container.Objects.Add(curve);
}

Target Platforms

Reference

AnnCurveObject Members
Leadtools.Annotations Namespace
