FreeRadialBendCommand Class

Example





Members
Wraps the image along its radius on a 3D surface shaped by Curve. This command is available in the Raster Pro and above toolkits. .NET support WinRT support
Object Model
FreeRadialBendCommand Class
Syntax
'Declaration

Public Class FreeRadialBendCommand
   Inherits Leadtools.ImageProcessing.RasterCommand
   Implements Leadtools.ImageProcessing.IRasterCommand
'Usage

Dim instance As FreeRadialBendCommand
public sealed class FreeRadialBendCommand : Leadtools.ImageProcessing.IRasterCommand
function Leadtools.ImageProcessing.SpecialEffects.FreeRadialBendCommand()
public ref class FreeRadialBendCommand : public Leadtools.ImageProcessing.RasterCommand, Leadtools.ImageProcessing.IRasterCommand
Remarks
For more information, refer to Correcting Colors.
Example

Public Sub FreeRadialBendCommandExample()
   Dim codecs As New RasterCodecs()
   codecs.ThrowExceptionsOnInvalidImages = True

   Dim leadImage As RasterImage = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "Master.jpg"))

   ' Prepare the command
   Dim command As FreeRadialBendCommand = New FreeRadialBendCommand
   Dim UserPoint() As LeadPoint
   ReDim UserPoint(3)
   Dim CenterPoint As LeadPoint = New LeadPoint(leadImage.Width \ 2, leadImage.Height \ 2)
   Dim Curve() As Integer
   ReDim Curve(12)

   'Apply the filter
   UserPoint(0).X = 0
   UserPoint(0).Y = 0
   UserPoint(1).X = 3
   UserPoint(1).Y = 10
   UserPoint(2).X = 9
   UserPoint(2).Y = -10
   UserPoint(3).X = 12
   UserPoint(3).Y = 0

   EffectsUtilities.GetCurvePoints(Curve, UserPoint, CurvePointsType.Linear)
   command.Flags = FreeRadialBendCommandFlags.Color Or FreeRadialBendCommandFlags.Rotate
   command.CenterPoint = CenterPoint
   command.Scale = 200
   command.FillColor = New RasterColor(255, 0, 0)
   command.Curve = Curve
   command.Run(leadImage)
   codecs.Save(leadImage, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24)

End Sub

Public NotInheritable Class LEAD_VARS
   Public Const ImagesDir As String = "C:\Users\Public\Documents\LEADTOOLS Images"
End Class
public void FreeRadialBendCommandExample()
   {
      // Load an image
      RasterCodecs codecs = new RasterCodecs();
      codecs.ThrowExceptionsOnInvalidImages = true;

      RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "Master.jpg"));

      // Prepare the command
      FreeRadialBendCommand command = new FreeRadialBendCommand();
      LeadPoint[] UserPoint = new LeadPoint[4];
      LeadPoint CenterPoint = new LeadPoint(image.Width / 2, image.Height / 2);
      int[] Curve = new int[13];

      //Apply the filter
      UserPoint[0].X = 0;
      UserPoint[0].Y = 0;
      UserPoint[1].X = 3;
      UserPoint[1].Y = 10;
      UserPoint[2].X = 9;
      UserPoint[2].Y = -10;
      UserPoint[3].X = 12;
      UserPoint[3].Y = 0;

      EffectsUtilities.GetCurvePoints(Curve, UserPoint, CurvePointsType.Linear);
      for(int i = 0; i < Curve.Length; i++)
         Curve[i] /= 50;
      command.Flags = FreeRadialBendCommandFlags.Color | FreeRadialBendCommandFlags.Rotate;
      command.CenterPoint = CenterPoint;
      command.Scale = 200;
      command.FillColor = new RasterColor(255, 0, 0);
      command.Curve = Curve;
      command.Run(image);
      codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

   }

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\Users\Public\Documents\LEADTOOLS Images";
}
Requirements

Target Platforms: Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2
