ColoredPencilCommandBitmapEffect Class
See Also  Members
Leadtools.Windows.Media.Effects.SpecialEffects Namespace : ColoredPencilCommandBitmapEffect Class




Applies an effect to an image that makes it look like it has been drawn with colored pencils. This method is available in the Raster Pro and above toolkits.

Syntax

Visual Basic (Declaration)
Public Class ColoredPencilCommandBitmapEffect
   Inherits RasterCommandBitmapEffect
Visual Basic (Usage)Copy Code
Dim instance As ColoredPencilCommandBitmapEffect
C#
public class ColoredPencilCommandBitmapEffect : RasterCommandBitmapEffect
Managed Extensions for C++
public __gc class ColoredPencilCommandBitmapEffect : public RasterCommandBitmapEffect
C++/CLI
public ref class ColoredPencilCommandBitmapEffect : public RasterCommandBitmapEffect

Remarks

  • This method applies an effect to an image that makes it look like it has been drawn with colored pencils.
  • As an example, if you use the following figure:

    If you call the ColoredPencilCommandBitmapEffect using the following values:
    Parameter Value
    Ratio 90
    Dimension 3

    The following figure results:
  • This method supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64 bit Effects images is available only in the Document/Medical toolkits.
  • This method does not support signed data images.
  • This command does not support 32-bit grayscale images.

Inheritance Hierarchy

System.Object
   System.Windows.Threading.DispatcherObject
      System.Windows.DependencyObject
         System.Windows.Freezable
            System.Windows.Media.Animation.Animatable
               System.Windows.Media.Effects.BitmapEffect
                  Leadtools.Windows.Media.Effects.RasterCommandBitmapEffect
                     Leadtools.Windows.Media.Effects.SpecialEffects.ColoredPencilCommandBitmapEffect

Requirements

Target Platforms: Microsoft .NET Framework 2.0, Windows 98, Windows NT 4.0, Windows Millennium Edition, Windows 2000, Windows XP Home Edition, Windows XP Professional, Windows Server 2003 family
