DiffuseGlowCommand Class
See Also  Members   Example
Leadtools.ImageProcessing.SpecialEffects Namespace : DiffuseGlowCommand Class




Adds a colored glow to an image's light or dark areas, making these areas shine with a neon glow. This method is available in the Raster Pro and above toolkits

Syntax

Visual Basic (Declaration)
Public Class DiffuseGlowCommand
   Inherits RasterCommand
   Implements IRasterCommand
Visual Basic (Usage)Copy Code
Dim instance As DiffuseGlowCommand
C#
public class DiffuseGlowCommand : RasterCommand, IRasterCommand
Managed Extensions for C++
public __gc class DiffuseGlowCommand : public RasterCommand, IRasterCommand
C++/CLI
public ref class DiffuseGlowCommand : public RasterCommand, IRasterCommand

Example

Visual BasicCopy Code
ImageProcessing.SpecialEffects.DiffuseGlowCommand
   Public Sub DiffuseGlowCommandExample()
      RasterCodecs.Startup()
      Dim codecs As New RasterCodecs()
      codecs.ThrowExceptionsOnInvalidImages = True

      Dim leadImage As RasterImage = codecs.Load("C:\Program Files\LEAD Technologies\LEADTOOLS 15\Images\Master.jpg")

      ' Prepare the command
      Dim fillColor As New RasterColor(255, 255, 255)
      Dim command As New DiffuseGlowCommand
      command.GlowAmount = 50
      command.ClearAmount = 50
      command.SpreadAmount = 10
      command.WhiteNoiseRange = 10
      command.GlowColor = fillColor
      command.Run(leadImage)
      codecs.Save(leadImage, "C:\Program Files\LEAD Technologies\LEADTOOLS 15\Images\Result.jpg", RasterImageFormat.Jpeg, 24)

      RasterCodecs.Shutdown()
   End Sub
C#Copy Code
ImageProcessing.SpecialEffects.DiffuseGlowCommand
      public void DiffuseGlowCommandExample()
      {
         // Load an image
         RasterCodecs.Startup();
         RasterCodecs codecs = new RasterCodecs();
         codecs.ThrowExceptionsOnInvalidImages = true;

         RasterImage image = codecs.Load(@"C:\Program Files\LEAD Technologies\LEADTOOLS 15\Images\Master.jpg");

         // Prepare the command
         RasterColor fillColor = new RasterColor(255, 255, 255);
         DiffuseGlowCommand command = new DiffuseGlowCommand () ;
         command.GlowAmount = 50;
         command.ClearAmount = 50;
         command.SpreadAmount = 10;
         command.WhiteNoiseRange = 10;
         command.GlowColor = fillColor;
         command.Run(image);
         codecs.Save(image, @"C:\Program Files\LEAD Technologies\LEADTOOLS 15\Images\Result.jpg", RasterImageFormat.Jpeg, 24);

         RasterCodecs.Shutdown();
      }

Remarks

  • This command adds pixels randomly to the image. A glow is added based on a combination of the pixel colors and the glow color.
  • As an example, if you use the following image:

    And you were to call DiffuseGlowCommand using the following settings:
    ParameterValue
    GlowAmount50
    ClearAmount50
    SpreadAmount10
    WhiteNoiseRange10
    GlowColorwhite

    The following figure results:
  • If the image has a region, the effect will be applied on the region only.
  • This method supports 12- and 16-bit grayscale and 48- and 64-bit color images. Support for 12- and 16-bit grayscale and 48- and 64-bit color images is available only in the Document/Medical toolkits.
  • This method does not support signed data images.
  • This command does not support 32-bit grayscale images.
For more information, refer to Removing Noise.

Inheritance Hierarchy

System.Object
   Leadtools.ImageProcessing.RasterCommand
      Leadtools.ImageProcessing.SpecialEffects.DiffuseGlowCommand

Requirements

Target Platforms: Microsoft .NET Framework 2.0, Windows 98, Windows NT 4.0, Windows Millennium Edition, Windows 2000, Windows XP Home Edition, Windows XP Professional, Windows Server 2003 family

See Also
