Technology / Multimedia

LEADTOOLS MPEG-2 Transport SDK with Support for MPEG-2, MPEG-4 and H264 Data

MPEG-2 Transport

With LEADTOOLS MPEG-2 Transport Stream SDK technology, developers can add complete support for one of the most popular multimedia formats today. MPEG-2 transport stream technology is used in digital television, unmanned aerial vehicles (UAV), Blu-ray media and more, and supports MPEG-2, MPEG-4 and H264 encoded video.

Overview of LEADTOOLS MPEG-2 Stream SDK Technology

MPEG-2 Transport and Related DirectShow Filters and Media Foundation Transforms

Hover over each for information. Click to go to more details.

  • Create MPEG-2 transport streams and MPEG-2 program files.
  • Add private data such as KLV data to a stream.
  • Supports all compressions supported by MPEG-2 transport format (ISO/IEC 13818-1).
  • AutoLive – automatically jump ahead if it drifts behind the live stream.
  • Play MPEG-2 transport streams and MPEG-2 program files without using the Microsoft demultiplexers.
  • Receive streaming MPEG-2 data through UDP ports.
  • Parse the private data such as KLV data from a stream.
  • Seek in byte mode.
  • Seek in files with incorrect timestamps.
  • Play all compressions supported by MPEG-2 transport format (ISO/IEC 13818-1).
    • Video
    • Audio
      • MPEG1 Layer 1, 2, 3
      • AAC
      • AC3 (Requires an AC3 audio decoder)
      • LPCM (Requires an LPCM audio decoder)
  • Built-in DVR support.
  • Automatically detects and handles RTP packets.
  • Unicast and multicast IP support.
  • Configurable listening port.
  • Network interface card (NIC) selection.
  • Supports both compressed and uncompressed streams
  • Unicast or Multicast IP support.
  • Configurable listening port.
  • Network interface card (NIC) selection.
  • Support for H264, MPEG4, JPEG, AMR, AAC, µ-Law and a-Law compression
  • Support for Unicast and Multicast streams over TCP, UDP or HTTP
  • Automatically detects and handles RTP packets
  • Configurable listening port
  • Can configure the server compression and other parameters
  • Easily create 1080 and 720 HDTV video.
  • MPEG-1 and MPEG-2 streams.
  • Low, main & high profiles implementation.
  • Inter-prediction accuracy of 1/2 pixel.
  • Preprocessing frame-rate adjustment.
  • Fixed and variable bit rate compression options with a wide range of quality factors.
  • Preset compression options for VCD, SVCD and DVD.
  • Supports linear and nonlinear quantization.
  • Supports frame rate adjustment.
  • Delivers 3 output formats: MP4V (standard), LMP4, and XVID. LMP4 is LEAD’s proprietary MPEG-4 video and includes options to achieve better compression performance.
  • Configurable motion estimation.
  • Mechanism for smoother playback of corrupted video data.
  • LEAD’s super compression option uses H.264 standard compression in an innovative way to produce super small streams using less resources when compared to other H.264 encoders. With this “super” performance it is possible to stream H.264 compatible videos in real time without additional hardware or excessive CPU usage making the super compression option ideal for video conference applications.
  • Play high definition formats (720p and 1080i) in real time.
  • User definable motion estimation settings controls the balance between encoder speed and quality.
  • Multiple reference frames of any combination of past and future frames, providing precise interprediction as well as improved robustness during packet loss while streaming over the network or Internet.
  • Unrestricted motion search uses reference frames that may be partly outside the frame improving network performance by predicting missing data.
  • Only the difference between motion vectors is saved, increasing the compression ratio.
  • Intraprediction may be performed either on 4x4 blocks or 16x16.
  • Motion vector prediction is performed before the frame is prepared for compression (pre-DCT) improving prediction and compression performance.
  • A context-sensitive deblocking filter smoothes out internal edges, significantly improving the visual quality of the video.
  • Employs Context-Adaptive Variable Length Coding (CAVLC) to encode transform coefficients.
  • The Context-Adaptive Binary Arithmetic Coding (CABAC) method continually updates frequency statistics of the incoming data and adaptively adjusts the algorithm, improving compression performance.
  • Control of the number of frame types encoded into the video stream.

The LEADTOOLS DVR Sink filter uses LEAD's intelligent time-shifting algorithm to write live video/audio streams to disk for playback. Developers have complete control of the buffer size including support to have the buffer span more than one disk.

The LEADTOOLS DVR Source filter reads video and audio streams from files created by the LEADTOOLS DVR Sink filter. With the DVR Source filter, the LEADTOOLS Player control can play, pause, rewind and fast forward live streams.

  • Advanced delta optimizations for encoding and decoding captured screen data.
  • Perfect for whiteboard, remote control and video conferencing applications.
  • Compress audio data using the MPEG-1 Layer 2 audio compression standard (ISO/IEC 11172-3).
  • Can be multiplexed into an MPEG-1 or MPEG-2 file.
  • Create MPEG-1 or MPEG-2 DVD files.
  • Supports both variable and constant bitrates.
  • Output channels selection.
  • Surround feature.
  • Supports both versions of AAC, MPEG-4 and MPEG-2.
  • Supports Low Complexity, Main, and Long Term Prediction profiles.
  • Supports 2 stream formats; Raw and ADTS.
  • Output sample frequency selection.
  • Cut-off frequency option.
  • Optionally force stereo output.
  • Supports Mono, Stereo and 5.1 Surround sound
  • Supports bitrates from 32kbps to 640kbps



LEADTOOLS Multimedia SDK evaluation with MPEG-2 Technology Download

Other LEADTOOLS SDK Technologies Related to MPEG-2 Transport

LEADTOOLS SDK Products that Include MPEG-2 Transport SDK Technology

Hover over each for information. Click to go to more details.

LEADTOOLS Multimedia Suite SDK

The Multimedia Suite SDK is a comprehensive collection of multimedia development technology from LEAD Technologies. By bundling features from the Multimedia SDK, DVD Module, Video Streaming Module, MPEG-2 Transport Module, Imaging Pro SDK and Cloud SDK, the Multimedia Suite provides everything a developer needs to create enterprise level multimedia applications for a wide variety of industries including defense, broadcast, security and more.

LEADTOOLS MPEG-2 Transport Module

The LEADTOOLS MPEG-2 Transport Module includes DirectShow filters & Media Foundation Transforms to create and play MPEG-2 Transport and MPEG-2 Program streams. Quickly convert from one file format to another without recompression such as MP4 to MPEG2. The LEADTOOLS MPEG-2 Transport Module is able to stream data over UDP and TCP with option RTP packets as well as utilizing RTSP servers and DVR.
