Datamatrix Barcodes in LEADTOOLS

Datamatrix is a two-dimensional matrix barcode consisting of black and white square modules arranged in either a square or rectangular pattern. The encoded information can be text or binary. Typical data storage size is from a few bytes up to 2 kilobytes. The total storage of the encoded data depends on the symbol dimension. Datamatrix barcodes also include error correction codes which increase symbol robustness. This means that a partially damaged Datamatrix barcode can still be successfully and accurately decoded.

LEADTOOLS Datamatrix Barcode SDK Symbols

Sample Barcode:

Datamatrix

Leadtools.Barcode support:

LEADTOOLS symbology identifier

BarcodeSymbology.Datamatrix

Data class

Leadtools.Barcode.DatamatrixBarcodeData

Read options

Leadtools.Barcode.DatamatrixBarcodeReadOptions

Write options

Leadtools.Barcode.DatamatrixBarcodeWriteOptions

LEADTOOLS Datamatrix SDK Supported Sub-Types

Datamatrix type (Leadtools.Barcode.DatamatrixBarcodeSymbolSize)

Maximum Numeric Length

Maximum Alphanumeric Length

Maximum Binary Length

Maximum Correctable Error / Erasure

10 x 10

6

3

1

2

12 x 12

10

6

3

3

14 x 14

16

10

6

5/7

16 x 16

24

16

10

6/9

18 x 18

36

25

16

7/11

20 x 20

44

31

20

9/15

22 x 22

60

43

28

10/17

24 x 24

72

52

34

12/21

26 x 26

88

64

42

14/25

32 x 32

124

91

60

18/33

36 x 36

172

127

84

21/39

40 x 40

228

169

112

24/45

44 x 44

288

214

142

28/53

48 x 48

348

259

172

34/65

52 x 52

408

304

202

42/78

64 x 64

560

418

278

56/106

72 x 72

736

550

366

72/132

80 x 80

912

682

454

96/180

88 x 88

1152

862

574

112/212

96 x 96

1392

1042

694

136/260

104 x 104

1632

1222

814

168/318

120 x 120

2100

1573

1048

204/390

132 x 132

2608

1954

1302

248/472

144 x 144

3116

2335

1556

310/590

8 x 18

10

6

3

3

8 x 32

20

13

8

5

12 x 26

32

22

14

7/11

12 x 36

44

31

20

9/15

16 x 36

64

46

30

12/21

16 x 48

98

72

47

14/25
